CHAPTER -2: YOUR FRIDGE
11
1
2
3
4
5
6
7
8
9
10
1) Turbo fan
2) Wine rack *
3) Fridge glass shelves
4) Upper crisper cover *
5) Upper crisper *
6) Bottom crisper cover
12
13
14
15
16
17
18
Water tank group
12) Filter cover
13) Top cover of the water tank
14) Tank cover
15) Water tank
16) Gasket ring
17) Tap detail
18) Side Locking covers
7) Bottom crisper
8) Bottle shelf
9) Door shelves
10) Water Tank *
11) Egg holder
* In some models
This gure has been drawn for information purposes to show the various parts and accessories in the appliance.
Parts may vary according to the model of the appliance.
19
20
21
22
Front water dispenser group
19) Top cover of the water dispenser
20) Valve lever
21) Drip tray
22) Water dispenser casing
