Sharp SM-307H - Specifications; Names of Parts

SM-307H
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT,
PLEASE REFER TO THE OPERATION MANUAL.
SPECIFICATIONS
Power consumption: 280W
Power source: AC 220V, 50/60 Hz (For Europe)
AC 240V, 50 Hz (For UK)
MPO: 4 x 50 W/8 ohms
0.8% total harmonic distortion
RMS: Total 120 W
Full range/Bass range; 2 x 30 W at 8
ohms, 0.8% T.H.D. (DIN 45 500)
Input sensitivity and VCR/CD/TV; 300 mV, 47 kohms
input impedance: Phono; 3 mV, 47 kohms
Tape/Tuner; 220 mV, 47 kohms
Loaded impedance: Speakers; 8 ohms
Headphones; 8 - 25 ohms
Dimensions: Width; 330 mm (13’’)
Height; 107 mm (4-3/16’’)
Depth; 329 mm (12-15/16’’)
Weight: 6.5 kg (14.4 Ibs.)
| Specifications for this model are subject to change
| without prior notice.
NAMES OF PARTS
- Spectrum Analyzer and Graphic Equalizer Display
. Spectrum Analyzer/Graphic Equalizer Selector Switch
. Function Selector Switches and Indicators
. Graphic Equalizer Flat Button
. Bass Level Control
. Balance Control
. Volume Control
. Mode Switch
» Surround Switch
. Power Switch
.
Graphic
Equalizer
Up/Down
Buttons
10
11
12
13
14
15
16
17
18
- Spectrum Analizer Display
Level
Control
. Graphic
Equalizer
Memory
Button
.
Graphic
Equalizer
Manual/Programmed
Selector
Figure
2-1
.
Graphic
Equalizer
Preset
Buttons
.
Headph
Socket
anaaaean
meaao
19
20
21
22
23
24
25
26
» Microphone Socket
- Mixing Level Control
. Tape Input/Output Socket
. CD Sockets
» TV Input Socket
- VCR Input Socket
» Tuner Input Socket
. Phono Input Socket
. Speaker Socket
. AC Power Supply Cord
Ne ee ee ee ey
CHO MDNODODAWN=|"OODNOUAWNH
N =
NNNNN
Onhwh
Figure 2-2
