PART LIST
REF. NO. PART NO. DESCRIPTION Q'TY PRICE CODE
ELECTRICAL PARTS
1- 1 FACCDA074WRE0 Power supply cord 1 AW
1- 2 QFS-BA009WRE0 Monitor fuse 20A and monitor switch (V-5220D-070) assembly 1 AH
1- 3 FPWBFA513WRKZ Noise filter 1
1- 3 FPWBFA496WRKZ Noise filter (Interchangeable) for producon use 1 AM
1- 4 QSW-MA168WRZZ Primary interlock switch/Thirdoor switch/Door sensing switch 3 AK
1- 4 QSW-MA085WRE0 "-----" (Interchangeable) 3 AF
1- 4 QSW-MA131WRE0 "-----" (Inter
changeable) 3 AG
1- 4 QSW-MA110WRE0 "-----" (Interchangeable) 3 AK
1- 5 FH-HZA128WREZ Thermistor 1 AQ
1- 6 QSW-MA168WRZZ Damper switch 1 AK
1- 6 QSW-MA085WRE0 "-----" (Interchangeable) 3 AF
1- 6 QSW-MA131WRE0 "-----" (Interchangeable) 3 AG
1- 6 QSW-MA110WRE0 "-----" (Interchangeable) 3 AK
1- 7 RTHM-A078WRE0 Magnetron thermal cut-out 125οC 1 AK
1- 8 RTHM-A121WRE0 Oven & Convecon thermal cut-out 150οC 2 AK
1- 9 RMOTDA2
56WRZZ Damper motor 1 AP
1-10 RLMPTA093WRZZ Oven lamp 1 AL
1-11 FDTCTA183WRK0 AH sensor assembly 1 AY
1-12 QSOCLA021WRE0 Oven lamp socket 1 AG
1-13 RMOTEA283WRE0 Convecon fan motor 1 AZ
1-14 RMOTEA300WRE0 Fan motor 1 AZ
1-15 RHET-A358WRZZ Heang element 1 AX
* 1-16 RTRN-A770WRZZ Power transformer 1
* 1 AS
*
1-17
RC-QZA331WRZZ
H.V.capacitor
1 AS
*
1-17
RC-QZA211WRE0
H.V.capacitor (Interchangeable)
1 AV
*
1-18
FH-DZA152WRKZ
H.V.recfier
assembly
1 AP
*
1-19
RV-MZA386WRZZ
Magnetron
1
1-20
RMOTDA314WRZZ Turntable motor
1
AX
1-21
DPWB-B451DRKZ
Power unit
CABINET PARTS
2- 1 GCABUB033WRPZ Outer case cabinet [A3R93D0PS] 1 BK
2- 1 GCABUB356WRPZ Outer case cabinet [A3R93D0PK] 1
2- 1 GCABUB357WRPZ Outer case cabinet [A3R93D0PW] 1
2- 2 PCOVPA171WRP0 CSA barrier 1 AC
2- 3 FDAI-A199WRY0 Base cabinet (Not Replaceable) 1
2- 4 GLEGPA019WRE0 Foot 4 AD
2- 5 GCABDA198WRWZ Re
ar cabinet (Not Replaceable) 1
2- 6 LHLDKA009WRF0 Cord holder 1 AD
2- 7 LBNDKA036WRP0 Capacitor holder 1 AG
2- 8 FHNG-A320WRMZ Oven hinge (Lower) 1
2- 9 PHOK-A137WRFZ Latch hook 1 AM
2-10 MLEVPA231WRF0 Switch lever 1 AE
2-11 GCOVHA347WRP0 Turntable motor cover 1 AE
CONTROL PANEL PARTS
LCD
RLCDSA265DRZZ
negave polarity, VA type
1
—
PSHEPA009DREZ
Black and white PET(KIMOTO D-105)
1
—
LHLD-A016DRFZ
ABS VE-0856 Black N1
1
PT200 VH
GPC817X3+1BS
PHOTO COUPLER (PC817X3NSZ0F)
1
AD
AN
AZ
BH
BB
BE
AX
AR
AH
-
-
-
AF
CN-G
QCNCWA057DRE0 12-pin connector (G) 1 AF
CN-N FW-VZA418DRZZ
4 pin Harness connector(N) 1
SP1 RALMBA007DRPZ Buzzer(UFPA22A) 1 AG
Note: The parts marked "Δ" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
42
PARTS LIST
SMC1585BSA
SMC1585BBA
SMC1585BWA
3-1 DPWB-B465DRKZ8 Control unit 1 BE
