Sharp SMO1854DS User Manual

30
INSTALL/REPLACE CHARCOAL FILTER
Charcoal Filter
If your oven is vented to the inside, the charcoal filter should be replaced if it is used for approximately
6 months.
You can purchase Charcoal Filter from 1-800-BE-SHARP.
CARE AND CLEANING
1. Unplug the oven or turn off the power at the main
power supply.
2. Remove the grille air mounting 3 screws and open
the door.
3. Slide the grille air to the left, then pull it straight out.
4. Push the charcoal filter backwards and remove it.
5. Slide a new charcoal filter into place. The filter
should rest at the angle.
6. Replace the grille air and 3 screws and close the
door.
7. Plug the oven in or turn on the power at the main
power supply.
CHARCOAL FILTER
GRILLE AIR

Sharp SMO1854DS Specifications

General

Style	over the range
Color	stainless steel
Total Capacity	1.8 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	3
Venting Type	non ducted
Sensor Cooking	yes
Quick Start	yes (1-6 minutes)
Control Type	touch control
Child Lock	yes
Timer	yes
Interior Light	led; yes
Microwave Power	1, 100 watts

Weight and Dimensions

Depth	15 9/10 inch
Height	16 3/10 inch
Width	29 9/10 inch
