Operation References
Operation References
1
Operation References
Part Names
For details on the use of each part, refer to the page number indicated in brackets.
Front view
Lithium battery
compartment door
[p. 11]
Stereo microphone
Zoom lens
Cassette holder [p. 10]
Cassette compartment door [p. 10]
Cassette compartment door release [p. 10]
DC input jack
[pp. 8, 9]
