Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
10-12
VL-E610S/VL-E610H
VL-E660S/VL-E96E
VL-E98E
R9404 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R9405 VRS-CZ1JF102J 1.0k 1/16W Metal Oxide AA
R9406 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R9451 VRS-CZ1JF333J 33k 1/16W Metal Oxide AA
R9452 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
PSLDM9124TAZZ Shield AD
P601 QPLGN0263TAZZ Plug AB
P901 QPLGN0664TAZZ Plug AD
P902 QPLGN0364TAZZ Plug AC
P2601 QPLGN0264TAZZ Plug AC
SC601 QSOCN1171TAZZ Socket AD
SC804 QSOCN2486TAZZ Socket AE
SC901 QSOCN0787TAZZ Socket AC
SC902 QSOCN1786TAZZ Socket AE
SC903 QSOCN1586TAZZ Socket AD
SC4701 QSOCN0860TAZZ Socket AE
SLD1 PSLDM3239TAFW Shield AC
SLD2 PSLDM3238TAFW Shield AC
RRMCK0034TAZZ Remote Control Pause AT
CABINET PARTS
P3301 QCNCM7068TAZZ Connector AG
DUNTK2785QA03 CAMERA UNIT(VL-E610S/E610H)
DUNTK2785QA04 CAMERA UNIT(VL-E96E)
DUNTK2785QA05 CAMERA UNIT(VL-E660S)
DUNTK2785QA06 CAMERA UNIT(VL-E98E)
INTEGRATED CIRCUITS
IC11 VHiUPD16510-1 UPD16510GR-8JG AR
IC12 VHiLR38590/-1 LR38590 AR
IC101 VHiCXA2006Q-1 CXA2006Q AV
IC102 VHiCXD2310A-1 CXD2310AR AV
IC201 RH-iX0470TAZZ HG73C002TE AY
IC251 RH-iX0490TAZZ IX0490TA BB
(VL-E660S/E98E)
IC252 VHiMS548331-1 MSM548331TS-K BD
(VL-E660S/E98E)
IC501 RH-iX0589TAZZ UPD784037GK513 AX
(VL-E660S/E98E)
IC501 RH-iX0590TAZZ UPD784036GK515 AW
(VL-E610S/E610H/E96E)
IC502 VHiMB8346BV-1 MB88346BPFV AN
IC503 VHiPST597KN-1 IC-PST597KNR AF
IC551 VHiMM1298XQ-1 MM1298XQ AV
IC552 VHiNJM2902V-1 NJM2902V AD
IC553 VHiNJM3414V-1 NJM3414AV AF
TRANSISTORS
Q11 VSUMX2/////-1 Transistor AB
Q201 VSUMX2/////-1 Transistor AB
Q202 VSUMT2/////-1 Transistor AB
Q203 VS2SC4617B/-1 Transistor AA
Q552 VSDTA114TE/-1 Transistor AA
DIODES AND LED’S
D501 VHDDA121///-1 Diode AA
D551 VHDDA121///-1 Diode AA
PACKAGED CIRCUITS
X11 RCRSZ0050TAZZ Crystal AS
COIL AND TRANSFORMERS
CF501 RFiLC0071TAZZ Filter AE
L11 VPAXM100KR42N Peaking 10µH 10% AC
L12 VPAXM470K1R7N Peaking 47µH 10% AC
L101 VPAXM100KR42N Peaking 10µH 10% AC
L102 VPAXM470K1R7N Peaking 47µH 10% AC
L201 VPAXM100KR42N Peaking 10µH 10% AC
L202 VPAXM470K1R7N Peaking 47µH 10% AC
L203 VPAWM100K1R5N Peaking 10µH 10% AC
L204 VPAWM6R8MR90N Peaking 6.8µH 20% AC
L205 VPABM3R9J1R6N Peaking 3.9µH5% AD
L207 VPAXM100KR42N Peaking 10µH 10% AC
L251 VPAXM100KR42N Peaking 10µH 10% AC
(VL-E660S/E98E)
L252 VPAXM100KR42N Peaking 10µH 10% AC
(VL-E660S/E98E)
L501 VPAXM100KR42N Peaking 10µH 10% AC
L551 VPAXM220KR88N Peaking 22µH 10% AC
L552 VPAXM220KR88N Peaking 22µH 10% AC
CAPACITORS
C11 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C12 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C13 VCKYTV1HB103K 0.01 50V Ceramic AA
C14 VCSATE1DJ475M 4.7 20V Tantalum AD
C15 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C16 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C17 VCSATJ1VJ685M 6.8 35V Tantalum AE
C18 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C19 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C20 VCSATA1AJ106M 10 10V Tantalum AC
C21 RC-KZ0051TAZZ Capacitor AC
