Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
10-15
VL-E610S/VL-E610H
VL-E660S/VL-E96E
VL-E98E
SC4 QSOCN1786TAZZ Socket AE
SC5 QSOCN0860TAZZ Socket AE
SC6 QSOCN2086TAZZ Socket AD
SC9 QSOCN1860TAZZ Socket AE
SLD3 PSLDM3321TAFW Shield AD
SLD4 PSLDM3322TAFW Shield AD
RAMP-0017TAN1 HEAD AMP UNIT
INTEGRATED CIRCUIT
IC301 VHiAN3358SH-1 H/A IC AQ
TRANSISTORS
Q301 VSUMG2/////-1 Transistor AC
or
VSXP1213///-1 Transistor AB
Q341 VS2SB709A/Q1E Transistor AC
Q342 VS2SB709A/Q1E Transistor AC
Q343 VSDTC144EE/-1 Transistor AA
or
VSUN9213///-1 Transistor AA
COILS
L301 VP-NM220K1R0N Peaking 22µH 10% AB
or
VPAXM220KR88N Peaking 22µH 10% AC
L341 VPABM100J2R6N Peaking 10µH5% AC
or
VPAWM100J2R6N Peaking 10µH5% AC
L342 VPABM101J160N Peaking 100µH5% AC
or
VPAWM101J140N Peaking 100µH5% AC
CAPACITORS
C305 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C306 VCCCCY1HH820J 82pF 50V Ceramic AA
C307 VCCCCY1HH820J 82pF 50V Ceramic AA
C308 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C309 VCKYCY1CF104Z 0.1µF 16V Ceramic AA
C310 VCKYCY1CF104Z 0.1µF 16V Ceramic AA
C311 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C312 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C313 VCSATE1AJ226M 22µF 10V Tantalum AD
C314 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C320 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C321 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C340 VCCCCY1HH101J 100pF 50V Ceramic AA
C341 VCCCCY1HH151J 150pF 50V Ceramic AA
C342 VCCCCY1HH101J 100pF 50V Ceramic AA
C344 VCKYCY1CF104Z 0.1µF 16V Ceramic AA
C345 VCKYCY1CF104Z 0.1µF 16V Ceramic AA
C346 VCKYCY1HB102K 1000pF50V Ceramic AA
C349 VCCCCY1HH680J 68pF 50V Ceramic AA
C350 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C351 VCKYCY1HF103Z 0.01µF 50V Ceramic AA
C352 VCCCCY1HH680J 68pF 50V Ceramic AA
RESISTORS
R302 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R303 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R310 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R311 VRS-CY1JF120J 12 1/16W Metal Oxide AA
R312 VRS-CY1JF120J 12 1/16W Metal Oxide AA
R315 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R321 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R330 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R331 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R332 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R333 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R340 VRS-CY1JF680J 68 1/16W Metal Oxide AA
R342 VRS-CY1JF271J 270 1/16W Metal Oxide AA
R343 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R344 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R345 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R350 VRS-CY1JF243J 24k 1/16W Metal Oxide AA
R351 VRS-CY1JF243J 24k 1/16W Metal Oxide AA
R352 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R353 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R398 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R399 VRS-CY1JF000J 0 1/16W Metal Oxide AA
CONNECTERS
SC301 QSOCN0985TAZZ Socket AE
SC302 QSOCN1886TAZZ Socket AD
SC303 QSOCN1560TAZZ Socket AE
SC304 QSOCN0686TAZZ Socket AC
SC305 QCNCW7068TAZZ Connector AG
SC306 QSOCN1085TAZZ Socket AE
MISCELLANEOUS PART
PSLDM0132ADG1 H/A Shield Case AC
