12-8
VL-E610S/VL-E610H
VL-E660S/VL-E96E
VL-E98E
CAUTION
*The AC plug configration varies depending on destinations.
ADP mode ... AC 240V input, during 3.5A rated load
CHG mode ... AC 240V input, during 5.5A battery charging
(in parentheses)
A
B
C
D
E
F
G
H
123456
å
AND SHADED COMPONENTS = SAFETY RELATED PARTS
• Each voltage represents actually measured value when the unit is using 240V AC
input and 3.5A ADP output.
• Parenthesized figures represent voltage values when the battery is charged using
240V AC input and 1.5A current.
Unit for resistor shall be Ω.
Resistor not specified shall be 1/10W.
Unit for capacitor shall be F.
R8, R21 and R66 are the parts for optional use.
å
12-3. AC ADAPTER CIRCUIT SCHEMATIC DIAGRAM
To Next Page
