Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
29
VL-E780U
VL-E785U
VL-E785T
11.REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
Les pièces marquéss " å " sont importantes pour maintenir la sècurité
de l'appareil. Ne remplacer ces pieces que par des pièces dont le
numéro est spécifié pour maintenir la sécurité et protéger le bon
fonctinnement de l'appareil.
" HOW TO ORDER REPLACEMENT PARTS "
in USA: Contact your nearest SHARP Parts Distributor. For
location of SHARP Parts Distributor,
Call Toll-free 1-IBE800-SHARP
★MARK : SPARE PARTS-DELIVERY SECTION:ALL JAPAN
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
å PIECES: RELATIVES A LA SECURITE
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
L'ASSEMBLANGE P.C.I. EST UN ARTICLE NON REMPLACABLE
Ref. No. Part No. ★ Description Code
Note :
In this chapter, only the differences from VL-E760U/765U
are described. Therefore, for the parts which are not
described in this page, refer to the Service Manual for VL-
E760U/765U (S38N2VL-E760U) chapter 11.
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK2782QA10 J VCR Unit(VL-E780U) —
DUNTK2782QA11 J VCR Unit(VL-E785U) —
DUNTK2782QA17 J VCR Unit(VL-E785T) —
DUNTK2785QA01 J CAMERA Unit —
DUNTK2782QA10 VCR UNIT(VL-E780U)
DUNTK2782QA11 VCR UNIT(VL-E785U)
DUNTK2782QA17 VCR UNIT(VL-E785T)
INTEGRATED CIRCUITS
IC703 RH-iX0609TAZZ J CXP87460-126R(VL-E785T)AY
IC705 RH-iX0612TAZZ J IX0612TA(VL-E785T) AR
TRANSISTORS
Q415 VS2PA1774R/-1 J Transistor AB
Q602 VSRT1N441U/-1 J Transistor AB
RESISTORS
R447 VRS-CZ1JF122J J 1.2k 1/16W Metal Oxide AA
R454 VRS-CZ1JF102D J 1k 1/16W Metal Oxide AA
R455 VRS-CZ1JF102D J 1k 1/16W Metal Oxide AA
R826 VRS-CZ1JF124D J 120k 1/16W Metal Oxide AA
R950 VRS-CZ1JF102J J 1k 1/16W Metal Oxide AA
R1820 VRS-CZ1JF393J J 39k 1/16W Metal Oxide AA
R1821 VRS-CZ1JF393J J 39k 1/16W Metal Oxide AA
DUNTK2785QA01 CAMERA UNIT
RESISTORS
R536 VRS-CZ1JF153J J 15k 1/16W Metal Oxide AA
R576 VRS-CZ1JF393J J 39k 1/16W Metal Oxide AA
R582 VRS-CZ1JF334D J 330k 1/16W Metal Oxide AA
