Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
31
VL-E780U
VL-E785U
VL-E785T
372 RAMP-0017TAN0 J H/A PWB AY
374 TLABH0196TAZZ J Caution Label AB
375 PSHEM0014GEZZ J Counter Balance AC
376 PSHEP0013GEZZ J Interruption Sheet AC
200 XAPSF17P03200 J Screw M1.7x3.2 AA
201 LX-XZ3036GEFP J Screw M2.0x6.0 AD
202 LX-BZ3175GEFN J Screw M1.7x4.0 AC
203 LX-BZ3163GEFN J Screw M1.7x2.5 AC
204 LX-HZ3074GEFN J Screw M1.7x5.3 S Tight AA
205 LX-BZ3177GEFF J Screw M1.4x1.5 AB
206 LX-BZ3132GEFF J Screw M1.4x1.5xD3.5 AA
207 LX-BZ3178GEZZ J Screw M1.4x1.5xD4.0 AD
208 LX-HZ3083GEFF J Screw M1.4x2.5 S Tight AB
209 LX-HZ3077GEFN J Screw M1.4x3.0 S Tight AA
211 LX-HZ3084GEFF J Screw M1.4x4.0 S Tight AC
212 LX-HZ3116GEFD J Screw M1.4x3.2 S Tight AB
213 LX-NZ3053GEZZ J Screw M1.4 Nut AC
214 LX-WZ1076GE02 J Washer D0.8xD3.0x0.2t AA
Plastics
215 LX-WZ1075GE02 J Washer D2.1xD5.0x0.25t AA
Plastics
216 XWHJZ12-02040 J Washer D1.2xD4.0x0.25t AC
Plastics
300 LCHSM0163GEZZ J Main Chassis Ass'y AW
301 NGERH1280GEZZ J Main Cam AD
302 NGERH1281GEZZ J Sub-Cam AD
303 MLEVF0470GEFW J Eject Lever AD
304 MLEVF0492GEFW J M Function Lever AF
305 LHLDZ1966GEZZ J L Block Holder AD
306 NGERW1064GEZZJ Worm Pulley AC
307 NGERW1065GEZZJ Worm AD
308 NGERH1282GEZZ J Worm Wheel AC
309 NGERH1283GEZZ J Lo Relay Gear AC
310 MARMM0126GEZZJ S Lo Arm Ass'y AE
311 MARMM0128GEZZJ T Lo Arm Ass'y AF
312 LANGA0069GEFW J S Lo Arm Retainer AD
313 PGiDM0146GEZZ J Sup Rail AD
314 PGiDM0171GEZZ J Tu Rail AD
315 NGERH1284GEZZ J Sup Lo Gear AC
316 NGERH1285GEZZ J Tu Lo Gear AC
317 MSPRD0167GEZZ J S Lo Arm Double-Acting AE
Spring
318 MSPRT0407GEZZ J T Lo Arm Double-Acting AC
Spring
319 MLEVP0310GEZZ J HC Lever Ass'y AF
321 MSLiF0074GEFW J Ten Arm Operation Lever AD
322 PGiDM0148GEZZ J Ten Arm Guide AC
323 NGERH3045GEFWJ Segment Gear AD
324 MLEVF0472GEZZ J Tu Guide Ass'y AC
325 PGiDP0027GEZZ J Tu Guide AE
326 MSPRC0183GEZZ J Tu Guide Spring AA
327 MSPRC0184GEZZ J Si Roller Spring AA
328 MSPRC0208GEZZ J Tu Guide Lever Spring AC
329 LCHSS0049GEZZ J Slide Chassis Ass'y AP
330 MLEVF0495GEZZ J Ten Arm Ass'y AC
331 LBNDK3023GEZZ J Ten Band Ass'y AF
332 NiDR-0016GEZZ J Swing Gear Ass'y AF
333 NGERH1286GEZZ J Driving Gear AC
334 NGERH1287GEZZ J Pulley Gear AD
335 NPLYV0157GEZZ J Relay Pulley AD
336 MLEVP0284GEZZ J S Brake AC
337 NGERH1288GEZZ J Tu Brake Gear AC
338 MLEVP0285GEZZ J Tu Main Brake AC
339 MLEVP0286GEZZ J Tu Sub-Brake AC
340 MSPRD0169GEZZ J Tu Brake Spring AD
341 LHLDZ2053GEZZ J Light Guide Holder Ass'y AF
342 LANGG9102GEFWJ Down Guide AF
343 MSPRT0408GEZZ J Tension Spring AD
344 MSPRD0170GEZZ J S Brake Spring AD
345 CDRMU0032GE01 J Upper Drum Ass'y BF
346 PGiDM0154GEZZ J Tape Guide AB
348 QBRSK0039GEZZ J Earth Spring AD
349 PGiDM0143GEZZ J Drum Base AG
350 DDRML0020HE01 J Lower Drum Ass'y AY
351 RMOTP1137GEZZ J Drum Motor AS
352 PSPAQ0010GEZZ J Gap Adjusting Shim AC
353 NRTR-0096GEZZ J R Tr Rotor Ass'y AP
354 MSPRC0209GEZZ J Gr Adjusting Spring AC
355 LPOLM0058GEZZ J S Pole Base AK
356 LPOLM0059GEZZ J T Pole Base AK
357 NDAiV1071GEZZ J Sup Reel Support AG
358 NDAiV1072GEZZ J Tu Reel Support AG
359 MLEVF0517GEZZ J Pinch Lever Ass'y AS
360 NBLTT0012GEZZ J Timing Belt S AE
361 NBLTT0013GEZZ J Timing Belt L AE
362 NROLP0108GEZZ J Guide Roller Ass'y AG
363 NROLP0109GEZZ J Si Roller Ass'y AH
364 QPWBH5428GEZZJ Mode FPC AG
365 CPWBN5402GE01 J Sensor Ass'y BC
366 QSW-M0042GEZZ J Recognition SW AH
367 RDTCH0037GEZZ J Dew Sensor AF
368 RMOTV1019GEZZ J Cap. Motor AZ
369 RMOTM1075GEZZJ Load. Motor AL
370 QSW-R0038GEZZ J Mode SW AG
MECHANISM PARTS
—— End of Mechanism Parts ——
OTHER PARTS
SUPPLIED ACCESSORIES
RRMCG0072TASA J Infrared Remote Control AP
(VL-E780U/785U)
RRMCG0073TASA J Infrared Remote Control
(VL-E785T)
TiNSE0313TAZZ J Operation Manual AG
(VL-E780U)
TiNSE0314TAZZ J Operation Manual AH
(VL-E785U)
TiNS-6013TAZZ J Operation Manual
(VL-E785T)
UBATM0010TAZZ J Battery (VL-E780U/785U) BC
UBATM0011TAZZ J Battery (VL-E785T) BC
UADP-0274TAZZ J AC Adapter —
(VL-E780U/785U)
UADP-0275TAZZ J AC Adapter (VL-E785T) —
ACCESSORIES (NOT REPLACEMENT ITEM)
UBATL0011TAZZ J Lithium Battery —
UBATU0023GEZZ J AA Drycell Battery —
PACKING PARTS (NOT REPLACEMENT ITEM)
SPAKC7399TAZZ – Packing Case(VL-E780U) —
SPAKC7403TAZZ – Packing Case(VL-E785U) —
SPAKC7404TAZZ – Packing Case(VL-E785T) —
SPAKP6049TAZZ – Wrapping Paper —
SSAKA0087TAZZ – Polyethylene Bag —
