Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
33
VL-E780U
VL-E785U
VL-E785T
12 PMiR-0022TAZZ J Reflection Sheet AD
å 13 CLMPV0045TA01 J Lamp Inverter Unit
14 CPNLC0030RM02 J LCD Panel CE
15 PZETV0370TAZZ J LCD Glass Retaining AB
16 TLABM1930TAZZ J Model Label(VL-E780U) AC
16 TLABM1934TAZZ J Model Label(VL-E785U) AC
16 TLABM1935TAZZ J Model Label AD
(VL-E785T)
16 TLABG0118TAZZ J Tax Paying Label AC
(VL-E785T)
17 TLABN0174TAZZ J Serial No. Label(VL-E780U)AC
17 TLABN0175TAZZ J Serial No. Label AC
(VL-E785U)
18 CLNSA0127TA01 J Lens Unit BS
19 GFTAC1241TASA J Cassette Compartment AD
Cover
20 DUNTK2782QA10 J VCR Unit(VL-E780U) —
20 DUNTK2782QA11 J VCR Unit(VL-E785U) —
20 DUNTK2782QA17 J VCR Unit(VL-E785T) —
21 DUNTK2785QA01 J Camera Unit —
22 QPWBH2814TAZZ J Tilt FPC AQ
23 LHLDW1038TA00 J FPC Holder AC
24 QSW-Z0287TAZZ J VCR Operation Unit AW
(VL-E780U/785U)
24 QSW-Z0301TAZZ J VCR Operation Unit AV
(VL-E785T)
25 QTANZ0129TAZZ J Battery Terminal Unit AG
26 QSW-Z0285TAZZ J Power Unit AR
27 LHLDZ1452TAZZ J Power Lock Holder AC
28 MSPRC0083TAFJ J Power Lock Spring AA
29 JBTN-0277TASB J Power Button AF
30 LHLDZ1451TAZZ J Power Holder AC
31 JKNBP0152TASA J Power Knob AD
32 JKNBP0153TASB J Zoom Knob AF
33 LHLDZ1453TASA J Zoom Knob Holder AD
34 JKNBP0154TASA J Open Knob AC
35 PSPAZ0191TAZZ J Spacer AA
36 RMiCC0079TAZZ J Microphone AM
37 MSPRT0034TAFJ J Lid Lock Spring AC
38 LHLDZ1454TA00 J VCR Lid Lock AD
39 NSFTZ0084TAFW J VCR Lid Shaft AD
40 PSPAZ0192TAZZ J Microphone Lead Spacer AD
41 LHLDZ1450TAZZ J Speaker Holder AC
42 VSP0020P-94WN J Speaker AL
43 PSPAG0103TAZZ J Speaker Spacer AC
44 PCOVP9062TAZZ J Speaker Mesh AB
45 PSPAG0095TAZZ J VCR Lid Cushion AA
46 GCOVA3056TAKA J Speaker Cover AE
47 ZTAPEZ800020E J Tape —
48 QSW-Z0284TAZZ J Turn/Eject SW AH
49 MLEVP0031TAZZ J Eject Lever AC
50 LANGK0399TAFW J Tripod Angle Ass’y AK
51 PSHEP0074TAZZ J Microphone Lead Sheet AB
52 QJAKZ0071TAZZ J Jack Unit AS
53 PSPAG0084TA00 J Front Group Frame AD
Rubber
54 GCOVA3057TAKA J Microphone Cover AG
55 QPWBH2815TAZZ J CCD FPC AS
56 PSPAZ0209TAZZ J LCD Spacer AF
a LX-HZ0018TAFN J M2x6 Tapping, Silver AA
b LX-HZ0018TAFF J M2x6 Tapping, Black AA
c LX-HZ0045TAFN J M2x4 Tapping, Silver AA
d XiPSF20P04000 J M2x4 Small Screw, Black AA
Zinc Plating
e LX-BZ0191TAFD J M2 Special Screw AC
f XiPSD20P03000 J M2x3 Screw AA
g LX-UZ0016TAFD J M2x5 Special Screw AA
h LX-BZ0200TAFD J M2x7 Special Screw AB
i XiPSN20P04000 J M2x4 Small Screw, Silver AA
j LX-HZ0063TAFC J M1.7x6 Tapping, Silver AA
1 DCABA6183TAK3 J V Frame Service AL
(VL-E780U)
1 DCABA6183TAK1 J V Frame Service AL
(VL-E785U)
1 DCABA6183TAK2 J V Frame Service AL
(VL-E785T)
1-2 PSPAG0095TAZZ J VCR Lid Cushion AA
1-3 TLABH0355TAZZ J Lithium Exchange Label AB
(VL-E780U/785U)
1-3 TLABH0259TAZZ J Lithium Exchange Label AD
(VL-E785T)
1-4 LHLDB1027TAZZ J Lithium Holder AD
2 DCABB6184TAK3 J L Cabinet Service AS
(VL-E780U/785U)
2 DCABB6184TAK4 J L Cabinet Service
(VL-E785T)
2-2 QEARP0234TAFJ J LCD Earth Sheet AE
2-3 TLABH0318TAZZ J Facing Recording Caution AB
Label (VL-E780U/785U)
2-3 TLABH0326TAZZ J Facing Recording Caution AB
Label (VL-E785T)
2-4 GCOVH1226TASA J Jack Cover AD
2-5 GCOVA1535TAZZ J Remote Control Receptor AD
Cover
3 CCABC6091TAK4 J Camera Front Cabinet AT
Ass’y
3-2 GCOVA1539TASB J Lens Hood AK
4 DCABD6088TAK4 J Camera Rear Cabinet AS
Ass’y (VL-E780U/785U)
4 DCABD6094TAK2 J Camera Rear Cabinet
Ass’y (VL-E785T)
4-2 JBTN-0276TASB J Camera Button AF
5 DFTAC1277TAK1 J VCR Lid Service AU
(VL-E780U)
5 DFTAC1278TAK1 J VCR Lid Service AU
(VL-E785U/T)
5-2 HBDGS0059TASB J LCD Badge AE
5-3 LANGK0428TAFW J VCR Lid Reinforcing Angle AG
5-4 LANGK0400TAFW J Eject Fitting AD
5-5 PSPAZ0193TAZZ J VCR Lid Sheet AC
5-6 MSPRD0047TAFJ J VCR Lid Spring AD
6 CCOVA1536TAK5 J KS Side Cover AU
(VL-E780U/785U)
6 CCOVA1536TAK8 J KS Side Cover AT
(VL-E785T)
6-2 NSFTZ0049TAFW J Battery Lid Axle AC
6-3 MSPRD0050TAFJ J Battery Lid Spring AC
6-4 TLABH0264TAZZ J Recycle Label AB
6-5 GFTAB1066TAKA J Battery Lid AE
6-6 HDECP0045TASA J Battery Decoration Plate AC
6-7 LHLDZ1448TA00 J Battery Intermediate Lock AC
6-8 MSPRC0103TAFJ J Battery Intermediate Lock AD
Spring
6-9 MSPRC0102TAFJ J Battery Lock Lever Spring AA
6-10 MLEVP0030TASA J Battery Lid Open/Close AC
Lever
6-11 LHLDZ1449TAZZ J Battery Lock Holder AC
6-12 MLEVP0029TASA J Battery Lock Lever AC
6-13 MSPRC0101TAFJ J Battery Push-out Spring AD
6-14 LHLDZ1445TAZZ J Lens Holder AD
6-15 LANGK0398TA00 J Battery Lid Angle Fitting AH
6-16 UBNDT0122TAZZ J Hand Strap
7 DCOVA1538TAK1 J Tilt Ass’y AU
7-2 PSPAZ0190TAZZ J Tilt Spacer AE
7-3 GCOVA1537TAKA J Tilt Frame V AL
7-4 PSPAZ0189TAZZ J Rotation Spacer AD
7-5 LANGH0071TAFW J Stopper Fitting AD
8 LHLDZ1447TAZZ J LCD Holder AG
9 PSHEP0048TAZZ J Diffusion Sheet AE
10 PSHEP0047TAZZ J Prism Sheet AH
11 PGiDM0026TAZZ J Light Guide Plate AH
CABINET PARTS LIST
—— End of Cabinet Parts ——
