Sharp WF-2100W User Manual

WF-2100W
– 14 –
A
B
C
D
E
F
G
H
1
2
34 5
6
Figure 14 WIRING SIDE OF P.W.BOARD (3/3)
1
2
C601
CN501
D601
C604
C603
C602
D602
D603
F601
T4A L 250V
D604
BK
RD
RD
BR
BL
RD
BK
RD
RD
SW601
VOLTAGE SELECTOR
AC 220-240 V AC 110-127 V
SO601
AC INLET
SOCKET
(241)
(241)
(241)
(241)
(241)
CON501
FROM MAIN PWB
P13 12 - A
BR
COLOR TABLE
RD(R)
OR
YL
GR
BL
VL
GY
WH(W)
BK
PK
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
PINK
POWER PWB-B
BATTERY B PWB-A5
BATTERY A PWB-A4
T601
POWER TRANSFORMER
AC POWER
SUPPLY CORD
AC 110-127 V/220-240 V, 50/60 Hz
