Model WH-A57
18
REF. NO
PARTS CODE
DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 71T107 INSTRUCTION BOOK 1
1-2 71U100 SET PACKING CASE 1
1-3 71U101 CARTON BOX 1
1-4 71U102 NAME PLATE 1
1-5 71B1051 LOWER PAD 1
1-6 71B1061 UPPER PAD 1
MECHANICAL PARTS
2-1 71U200ASY BODY ASS’Y 1
2-2 7N7122 TEMP. CONTROL KNOB 1
2-3 7N706 SPLIT PIN 1
2-4 7N6182 BREAKER ANGLE SUPPORT 1
2-5 7K102 WATER OUTLET 1
2-6 7D9241 PLUG 2
2-7 71B201 BACK COVER 1
2-8 7D601 AC LINE CLAMP 1
2-9 7N608 RUBBER CAP 1
2-10 7K727 FITTING PLATE 1
2-11 7A220 CLAMPING SPRING 2
2-12 71T216ASY BODY VALVE ASS’Y 1
2-13 71T215 INSULATION SHEET 1
2-14 71B401SET HEATER TANK SET 1
2-15 7K1361 HEATER TANK SUPPORT 1
2-16 7K137 CABLE TIES 1
2-17 71A2041ASY SHOWER ASS’Y 1
2-18 7A901ASY SHOWER HOSE ASS’Y 1
2-19 7A910 SHOWER STAND 1
2-20 7D924ASY WATER VOLUME ASS’Y 1
2-21 7A912 O-RING FIXER 1
ELECTRIC PARTS
3-1 7A605 BREAKER 220V, 30A 1
3-2 71T411 BREAKER LEAD WIRE BLACK 1
3-3 7K442ASY PCB LAMP ASS’Y 1
3-4 7B404AASY VOLUME SWITCH SET 1
3-5 7N405 REED SWITCH ASS’Y 1
3-6 71T412 BREAKER LEAD WIRE WHITE 1
3-7 71T415 PCB CONTROL ASS’Y 1
3-8 71T407 TRIAC LEAD WIRE BROWN 1
3-9 71T416 THERMOSTAT LEAD WIRE BLACK 1
3-10 7N1261 THERMOSTAT 85
o
C 1
3-11 7A127 TRIAC 600V, 25A 1
3-12 71B413 L-WIRE-EARTH 1
