Sharp WH-HOT HOT - Replacing Method For Main Parts; Remove of Shower Hose; Remove of Body

10
1. Remove the screw underneath the unit.
2. Open the cover by lifting from the bottom.
3. Now the body is free.
REMOVE OF BODY
REPLACING METHOD FOR MAIN PARTS
1. Turn out the joint body between the body with the shower hose manually. Never use other tools to
avoid breaking plastic parts.
REMOVE OF SHOWER HOSE
Fig. 20
Body
Shower hose
Body
Screw
Back cover
Fig. 21
