MX-M200D SIMULATIONS 7-1
[7] SIMULATIONS
1. Entering the simulation mode
Perform the following procedure to enter the simulation mode.
[#] key [ ] key [C] key [ ] key
Main code [START] key Sub code [START] key
2. Canceling the simulation mode
When the clear all key is pressed, the simulation mode is cancelled.
When the interruption key is pressed, the process is interrupted and the
screen returns to the sub code entering display.
* After canceling the simulation mode, be sure to turn OFF/ON the
power and check the operation.
Note: If the machine is terminated by a jam error or paper empty during
copying in the adjustment by the simulation, recopying is required.
Note:The values in the simulation columns are not default values but
sample values.
3. List of simulations
Main
code
Sub
code
Contents
01 01 Mirror scanning operation
02 Mirror home position sensor (MHPS) status display
02 01 Single paper feeder (SPF)/Reversing single pass
feeder(RSPF) aging *2
02 SPF/RSPF sensor status display *2
03 SPF/RSPF motor operation check *2
08 SPF/RSPF paper feed solenoid operation check *2
09 RSPF reverse solenoid operation check *2 *3
11 SPF/RSPF PS release solenoid operation check *2
03 02 Shifter/job separator sensor status display
03 Shifter operation check
04 Job separator operation check *4
11 Shifter home position check
05 01 Operation panel display check
02 Fusing lamp and cooling fan operation check
03 Copy lamp lighting check
06 01 Paper feed/transport solenoid operation check
02 Resist roller solenoid (RRS) operation check
10 Main cassette pickup roller cleaning
07 01 Warm-up display and aging with jam detection
06 Intermittent aging
08 Shifting with warm-up display
08 01 Developing bias output
02 Main charger output (Grid = HIGH)
03 Main charger output (Grid = LOW)
06 Transfer charger output
09 01 Duplex motor forward rotation check *6
02 Duplex motor reverse rotation check *6
04 Duplex motor RPM adjustment *6
05 Duplex motor switchback time adjustment
10 - Toner motor operation
14 - Trouble cancel (except for U2)
16 - U2 trouble cancel
20 01 Maintenance counter clear
21 01 Maintenance cycle setting
22 01 Counters display
03 Jam memory display
04 Jam total counter display
07 Key operator code display
09 Paper feed counter display
13 CRUM destination display *5
14 P-ROM version display
15 Trouble memory display
22 SPF/RSPF jam counter display *2
24 01 Jam total counter clear
02 Trouble memory clear
04 SPF/RSPF counter clear *2
05 Duplex print counter clear *6
06 Paper feed counter clear
07 Drum counter clear
08 Copy counter clear
09 Printer counter clear
13 Scanner counter clear
14 SPF/RSPF jam total counter clear *2
15 Scanner mode counter clear
25 01 Main motor operation check (Cooling fan motor rotation
check)
