ENGLISH
E-4
General Information
- Controls and Indicators -
Controls and Indicators (continued)
„
Rear panel
Reference page
1. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.AM Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
3.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
4.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
5. CD Digital Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 22
7.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
8. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
„
Speaker system
1. Tweeter
2.Woofer
3.Bass Reflex Duct
4.Speaker Terminals
Speaker grilles are removable:
Placing the speaker system:
There is no distinction between the right and the left speakers.
2
1
3
4
5
6
7
8
MODEL NO. XL-1000H
COMPACT AUDIO SYSTEM
230 V ~ 50 Hz 30 W
SERIAL NO.
SHARP CORPORATION
<The bottom of the unit>
(XL-1000H)
MODEL NO. XL-1100H
COMPACT AUDIO SYSTEM
230 V
~ 50 Hz 30 W
SERIAL NO.
SHARP CORPORATION
(XL-1100H)
4
3
2
1
Make sure nothing comes into contact with the
speaker diaphragms when you remove the
speaker grilles.
Left speaker Right speaker
