Sharp XL-3000

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-3000/3000C
R806 VRS-CY1JB153J J AA 15 kohms,1/16W
R807 VRS-CY1JB103J J AA 10 kohm,1/16W
R808 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R809 VRS-CY1JB103J J AA 10 kohm,1/16W
R810 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R811 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R812 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R813 VRD-ST2EE100J J AA 10 ohm,1/4W
R814 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R815,816 VRD-ST2CD103J J AA 10 kohm,1/6W
R817,818 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R819 VRD-ST2CD221J J AA 220 ohms,1/6W
R820 VRS-CY1JB102J J AA 1 kohm,1/16W
R821 VRD-ST2CD151J J AA 150 ohms,1/6W
R822 VRD-ST2EE330J J AA 33 ohms,1/4W
R823 VRD-ST2CD102J J AA 1 kohm,1/6W
R824 VRS-CY1JB273J J AA 27 kohms,1/16W
R825 VRS-CY1JB823J J AA 82 kohms,1/16W
R826 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R827 VRS-CY1JB393J J AA 39 kohms,1/16W
R828 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R829 VRD-ST2CD683J J AA 68 kohms,1/6W
R830~837 VRS-CY1JB102J J AA 1 kohm,1/16W
R843 VRD-ST2CD102J J AA 1 kohm,1/6W
R851 VRS-CY1JB331J J AA 330 ohms,1/16W
R852~855 VRS-CY1JB104J J AA 100 kohm,1/16W
R861~863 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R873 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R874 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R876 VRS-CY1JB154J J AA 150 kohms,1/16W
R877 VRS-CY1JB683J J AA 68 kohms,1/16W
R879 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R901 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R902 VRS-CY1JB473J J AA 47 kohms,1/16W
R904 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R905 VRS-CY1JB473J J AA 47 kohms,1/16W
R910 VRD-ST2EE272J J AA 2.7 kohms,1/4W
R911 VRD-ST2EE101J J AA 100 ohm,1/4W
R912 VRD-ST2EE471J J AA 470 ohms,1/4W
R913 VRD-ST2EE100J J AA 10 ohm,1/4W
R914 VRD-ST2CD471J J AA 470 ohms,1/6W
OTHER CIRCUITRY PARTS
CFW451,452 QCNWN0308SJZZ J Lead Wire
CFW701A,B QCNWN0292SJZZ J AD Flat Wire,3Pin
CFW852 QCNWN0303SJZZ J Lead Wire
CNP307 QCNCM010LAWZZ J AC Plug,11Pin
CNP607 QCNCM999CAFZZ J AG Plug,3Pin
CNP651 QCNCM017BSJZZ J AD Plug,3Pin
CNP701 QCNCM999BAFZZ J AD Plug,2Pin
CNP702 QCNCM999QAFZZ J Plug,15Pin
CNP703 QCNCM999NAFZZ J Plug,13Pin
CNP704 QCNCM004BAFZZ J Plug,2Pin
CNP707 QCNCM998CAFZZ J AE Plug,3Pin
CNP801 QCNCM037ESJZZ J AD Plug,5Pin
CNP802 QCNCW007RSJZZ J AF Socket,16Pin
CNP803 QCNCM035FSJZZ J AD Plug,6Pin
CNP804 QCNCM038BSJZZ J Plug,2Pin
CNP805 QCNCM004CAFZZ J Plug,3Pin
CNP806 QCNCM004CAFZZ J Plug,3Pin
CNS307 QCNCW010LAWZZ J AD Socket,11Pin
CNW3 QCNWN0288SJZZ J AE Flat Cable,16Pin
CNW607/CNS607 QCNWN0291SJZZ J AE Connector Ass’y,3/3Pin
CNW701/CNS701 QCNWN0271SJZZ J AD Connector Ass’y,2/2Pin
CNW702/CNS702 QCNWN0269SJZZ J AG Connector Ass’y,15/15Pin
CNW703/CNS703 QCNWN0293SJZZ J AG Connector Ass’y,13/13Pin
CNW704/CNS704 QCNWN0297SJZZ J Connector Ass’y,2/2Pin
CNW707/CNS707 QCNWN0125SJZZ J AE Connector Ass’y,3/3Pin
CNW803/CNS803 QCNWN0252SJZZ J AE Connector Ass’y,6/6Pin
CNW804/CNS804 QCNWN0290SJZZ J AD Connector Ass’y,2Pin
CNW805/CNS805 QCNWN0296SJZZ J AE Connector Ass’y,3/3Pin
CNW806/CNS806 QCNWN0270SJZZ J AE Connector Ass’y,3/3Pin
1 F651,652 QFS-D322BSJNI J AC Fuse,3.15A/125V
1 F653 QFS-D162BSJNI J AE Fuse,1.6A/125V
J601 QJAKM0001SJZZ J AG Jack,Headphones
J801 VHPPLT130T2-1 J AM Jack,CD Degital Output
LCD701 RV-LX0012SJZZ J AR LCD Display
LMP701 RLMPP0001SJZZ J AT Lamp
M801 RMOTV0004SJM1 J AM Motor with Gear [CD Lid]
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408SJM1 J AR Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
1 RLY601 RRLYD0004SJZZ J AG Relay
RX701 VHLN61V380A-1 J AN Remote Sensor
SO301 QTANC9003SJZZ J AF Terminal,Antenna
SO401 QSOCJ0301SJZZ J AG Socket,Video/AUX Input/Sub
Woofer Out
SO601 QTANA0007SJZZ J AF Terminal,Speaker
1 SO655 QSOCA0214AWZZ J AD Socket AC Input
SW709 QSW-K0004SJZZ J AD Switch,Key Type [POWER]
SW710 QSW-K0004SJZZ J AD Switch,Key Type
[CD Lid Open/Close]
SW711 QSW-K0004SJZZ J AD Switch,Key Type [FF/Preset Up]
SW712 QSW-K0004SJZZ J AD Switch,Key Type
[CD Play/Pause/Tuning Up]
SW713 QSW-K0004SJZZ J AD Switch,Key Type [Volume Up]
SW718 QSW-K0004SJZZ J AD Switch,Key Type [Volume Down]
SW721 QSW-K0004SJZZ J AD Switch,Key Type [Bass/Treble]
SW722 QSW-K0004SJZZ J AD Switch,Key Type [Memory/Set]
SW725 QSW-K0004SJZZ J AD Switch,Key Type
[CD Stop/Tuning Down]
SW726 QSW-K0004SJZZ J AD Switch,Key Type
[REW/Preset Down]
SW727 QSW-K0004SJZZ J AD Switch,Key Type [Function]
SW802 QSW-B0001SJZZ J AG Switch,Lever Type [CD Lid]
CD MECHANISM PARTS
301 NGERH0586AFZZ J AC Gear,Middle
302 NGERH0587AFZZ J AC Gear,Drive
303 MLEVP0010AFZZ J Rail,Guide
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCOVP1333AFSA J AF Cover,Mechanism
306 PCUSG0001AWSA J AD Cushion (Green)
307 PCUSG0004AWSA J AD Cushion (Red-Brown)
1 308 DCTRH8005SJ01 J BA Pickup Unit Ass’y
308- 1 ———— — Pickup Unit
(Not Replacement Item)
308- 2 NGERR0043AFZZ J AC Gear,Rack
308- 3 NSPRC0961AFZZ J Spring,Rack
701 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
702 XBBSD20P03000 J AA Screw,ø2×3mm
703 XBSSD26P06000 J AA Screw,ø2.6×6mm
704 XHBSD20P05000 J AA Screw,ø2×5mm
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408SJM1 J AR Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
200 GCABA1062SJSA J AM Front Cabinet
201 GCABB1062SJSA J AL Bottom Cabinet [XL-3000]
201 GCABB1066SJSA J Bottom Cabinet [XL-3000C]
202 GCOVA1006SJSA J AK Rear Panel [XL-3000]
202 GCOVA1010SJSA J Rear Panel [XL-3000C]
203 GCOVA1005SJSA J AE Cover,Remote Sensor
204 GFTAT1008SJSA J AN CD Lid
205 LANGQ0002SJFW J Lug
206 HDECQ0050SJSA J AM Clear Panel,CD Lid
207 HDECQ0051SJSA J AE Clear Panel,Display
208 JKNBZ0055SJSA J AF Knob,Operation A
209 JKNBZ0056SJSA J AF Knob,Operation B
210 LANGF0033SJFW J Bracket,Main PWB
211 LANGF0034SJFW J Bracket,Tuner PWB
212 LANGF0035SJFW J Bracket,Gear Box
213 LANGK0025SJFW J AE Bracket,Tuner PWB
214 LANGK0026SJFW J Cover,Lamp
215 LCHSM0014SJFW J AH Chassis
216 LHLDW1001SJZZ J AD Nylon Band
217 LHLDZ1033SJSA J AD LCD Holder,A
218 LHLDZ1034SJSA J AD LED Holder
219 LHLDZ1035SJSA J AE Gear Box
220 LHLDZ1036SJSA J AE Lid,Gear Box
221 LPLTP0001SJSA J AE Cam Plate
222 MLEVP0006SJSA J AE Rotate Lever,CD Lid,Left
223 MLEVP0007SJSA J AE Rotate Lever,CD Lid,Right
224 NGERW0004SJSA J AE Drive Gear,A
225 NGERW0005SJSA J AE Drive Gear,B
226 NGERW0006SJSA J AG Drive Gear,C
1 227 PCOVW1014SJZZ J Fuse Cover [XL-3000C Only]
228 PCOVU9002SJZZ J AB Felt,CD Lid Cover
229 PCOVZ1005SJSA J AE Indicator Panel
230 PCUSG0003SJZZ J AC Cushion,Leg
– 4 –
