Sharp XL-3000

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
XL-3000/3000C
PRICE
RANK
DESCRIPTIONNO.
PARTS CODE
231 PGUMS0002SJZZ J Cushion,CD Lid
232 PRDAR0044SJFW J Radiator,Main
233 PRDAR0038SJFW J Radiator,Transistor
234 PREFL0001SJSA J LCD Diffusion Plate
235 PSHEP0003SJZZ J AE Sheet,LCD
236 PSHEP0004SJZZ J AD LCD Reflect Paper
237 QFSHD0001AWZZ J AB Holder,Fuse
238 TLABS0004SJZZ J AC Label,Laser
239 TLABS0036SJZZ J Label,Class 3A
240 TSPC-0229SJZZ J Label,Specification [XL-3000C]
240 TSPC-0243SJZZ J Label,Specification [XL-3000]
241 PCOVS3005SJFW J Plate,Shield
242 PSHEP0005SJZZ J Sheet,Shield
243 LANGJ0002SJFG J Connection Boss
244 PCOVQ1001SJSA J Cover,Radiator
601 LX-EZ0001SJFN J AB Screw,ø2.5×10mm
602 LX-WZ7094AFZZ J AA Screw,Special Type
603 XEBSD25P08000 J AA Screw,ø2.5×8mm
604 XEBSD25P10000 J AA Screw,ø2.5×10mm
605 XEBSD25P12000 J AA Screw,ø2.5×12mm
606 XEBSF25P08000 J AA Screw,ø2.5×8mm
607 XHBSD20P05000 J AA Screw,ø2×5mm
608 XHBSD30P06000 J AA Screw,ø3×6mm
609 XHBSD40P08000 J AA Screw,ø4×8mm
610 XJBSD30P06000 J AA Screw,ø3×6mm
611 XJBSD30P08000 J AA Screw,ø3×8mm
612 XJBSD30P10000 J AA Screw,ø3×10mm
613 XJBSD30P14000 J AA Screw,ø3×14mm
614 XJBSF30P08000 J AA Screw,ø3×8mm
615 XJBSF30P10000 J AA Screw,ø3×10mm
616 XJBSD30P18000 J AA Screw,ø3×18mm
SPEAKER BOX PARTS
901 CPNLS1006SJ01 J AS Front Panel Ass’y
902 GBOXS0009SJSA J AZ Box Ass’y
903 GWAKP1016SJ01 J AM Net Flame Ass’y
904 PDUC-0001SJZZ J AE Duct Pipe
905 PGUMM0003SJSA J AD Net Catcher
906 PSPAG0002SJZZ J AD Gsket
907 QTANA9011SJZZ J AE Terminal
908 TSPC-0225SJZZ J AD Label,Specification
909 92LHSY042SPK07 J Capacitor,3.3 µF,50V (N.P.)
910 XTBSF40P12000 J AA Screw,ø4×12mm
SP1,2 RSPA00006SJZZ J Woofer
SP3,4 RSPA00004SJ6T J AK Tweeter
PACKING PARTS [Except for U.S.A.]
SPAKA0058SJZZ J Packing Add.,Left
SPAKA0059SJZZ J Packing Add.,Right
SPAKA0068SJZZ J Packing Add.,Speaker
[Top/Bottom]
SPAKC0166SJZZ J Packing Case
SPAKS0001SJZZ J Sleeve Carton,Speaker
SPAKZ0008SJZZ J Polyethylene Bag,Speaker
SPAKZ0030SJZZ J Pad,Accessories
SPAKZ0064SJZZ J Polyethylene Bag,Unit
SSAKA0002SJZZ J AE Polyethylene Bag,Accessories
TLABE0080SJZZ J Label,Bar Code [XL-3000C]
TLABN0125SJZZ J Label,Serial No.
TLABZ0015SJZZ J AC Label,VJ No.
TLABZ0038SJZZ J AC Label,Energy
ACCESSORIES
1 QACCD0001SJ00 J AQ AC Power Supply Cord
QANTL0001SJZZ J AK AM Loop Antenna
QANTW0002SJZZ J AH FM Antenna
QCNWH0005SJ01 J Speaker Cord
PCUSG0009SJZZ J Cushion Leg
RRMCG0029SJSA J AS Remote Control
GCABB1064SJSA J Battery Lid,Remote Control
TINSE0060SJZZ J AE Operation Manual [XL-3000]
TINSK0028SJZZ J Operation Manual [XL-3000C]
TINSZ0096SJZZ J Quick Guide [XL-3000]
TINSZ0112SJZZ J Caution Sheet
– 5 –
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~8 DCEKLV025SJ03 J Main/Tuner/Display/Terminal/
Switch/Led/Lamp/Holder
1 PWB-B DCEKJV025SJ03 J Power
PWB-C QPWBF3895AFZZ J AC CD Motor (PWB Only)
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
