Sharp XL-3000H Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-1000H/1100H
C358 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C360,361 VCKYCY1EF223Z J AB 0.022 µF,25V
C362 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C363 VCKYCY1EF223Z J AB 0.022 µF,25V
C364 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C365 VCKYCY1EF223Z J AB 0.022 µF,25V
C366 VCKYCY1HB102K J AA 0.001 µF,50V
C367,368 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C369 VCCSCY1HL560J J AD 56 pF,50V
C370 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C371,372 RC-EZD105AF1H J AB 1 µF,50V,Electrolytic
C373,374 VCTYPA1CX183K J AA 0.018 µF,16V
C380 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C381 VCCCCY1HH120J J AA 12 pF (CH),50V
C382 VCCCCY1HH150J J AA 15 pF (CH),50V
C383 VCKYCY1EF223Z J AB 0.022 µF,25V
C384 VCKYCY1HB102K J AA 0.001 µF,50V
C385 VCKYPA1HF103Z J AB 0.01 µF,16V
C386 VCKYPA1HB331K J AA 330 pF,50V
C387 VCKYCY1EF223Z J AB 0.022 µF,25V
C391 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C392 VCKYCY1HB102K J AA 0.001 µF,50V
C393 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C394 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C395 VCKYCY1EF223Z J AB 0.022 µF,25V
C396 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C397 VCKYCY1EF223Z J AB 0.022 µF,25V
C398 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C399 VCKYPA1HF223Z J AB 0.022 µF,50V
C401~404 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C407,408 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C411 VCKYPA1HB331K J AA 330 pF,50V
C412 VCKYPA1HB331K J AA 330 pF,50V
C413 VCKYPA1HB472K J AB 0.0047 µF,50V
C415,416 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C417,418 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C419,420 VCKYCY1HB272K J AA 0.0027 µF,50V
C421~424 RC-QZA104AFYJ J AC 0.1 µF,50V,Mylar
C425,426 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C429 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C430 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C431~433 VCKYCY1HB221K J AA 220 pF,50V
C603 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C604 VCCSPA1HL470J J AA 47 pF,50V
C605 VCCSPA1HL470J J AA 47 pF,50V
C617,618 VCKYPA1HB472K J AB 0.0047 µF,50V
C620 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C621 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C622 VCKYPA1HF223Z J AB 0.022 µF,50V
C624 VCKYPA1HF223Z J AB 0.022 µF,50V
C625 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C626 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C627 VCKYPA1HF223Z J AB 0.022 µF,50V
C628 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C629 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C630 RC-GZW478AF1E J AG 4700 µF,25V,Electrolytic
C632,633 VCKYPA1HF223Z J AB 0.022 µF,50V
C636,637 VCKYPA1HF223Z J AB 0.022 µF,50V
C639,640 VCKYPA1HB472K J AB 0.0047 µF,50V
C651 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C654 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
1 C657~660 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C661 VCKYPA1HB102K J AA 0.001 µF,50V
C665 VCFYFA1HA473J J AB 0.047 µF,50V,Thin Film
C666,667 VCKYPA1HB821K J AA 820 pF,50V
C668 VCKYPA1HB391K J AA 390 pF,50V
C683 RC-GZV228AF1C J AG 2200 µF,16V,Electrolytic
C688 VCFYFA1HA473J J AB 0.047 µF,50V,Thin Film
C689 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C701,702 VCCCCY1HH220J J AA 22 pF (CH),50V
C703 VCKYCY1EF104Z J AA 0.1 µF,25V
C704 VCKYCY1EF223Z J AB 0.022 µF,25V
C705 VCKYPA1HF103Z J AB 0.01 µF,16V
C710 VCKYCY1EB103K J AA 0.01 µF,25V
C711 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C712 VCKYCY1EB103K J AA 0.01 µF,25V
C713 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C714 VCKYCY1HB561K J AA 560 pF,50V
C715 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C801 VCCSCY1HL101J J AA 100 pF,50V
C802 VCKYCY1EB153K J AA 0.015 µF,25V
C803 RC-EZD476AF1A J AC 47 µF,10V,Electrolytic
C804 VCKYCY1EB103K J AA 0.01 µF,25V
C805 VCKYCY1HB272K J AA 0.0027 µF,50V
C806 VCKYCY1HB472K J AA 0.0047 µF,50V
C807 VCKYCY1EB333K J AC 0.033 µF,25V
C809 VCKYCY1HB472K J AA 0.0047 µF,50V
C810 VCKYCY1HB102K J AA 0.001 µF,50V
C811 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C812 VCKYCY1EF103Z J AA 0.01 µF,25V
C813 RC-EZD107AF1A J AB 100 µF,10V,Electrolytic
C817~819 VCKYCY1EB104K J AD 0.1 µF,25V
C820 VCKYCY1EF103Z J AA 0.01 µF,25V
C821 VCKYCY1EB104K J AD 0.1 µF,25V
C822 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C823 VCKYCY1EF103Z J AA 0.01 µF,25V
C824,825 VCKYCY1EB563K J AD 0.056 µF,25V
C826,827 VCCCCY1HH150J J AA 15 pF (CH),50V
C828 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C829 RC-EZD107AF1A J AB 100 µF,10V,Electrolytic
C830 VCKYCY1EB563K J AD 0.056 µF,25V
C831,832 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C833,834 VCKYCY1HB471K J AA 470 pF,50V
C835 VCKYCY1EB563K J AD 0.056 µF,25V
C836 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C837 VCKYCY1HB471K J AA 470 pF,50V
C837A RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C838 RC-EZD476AF1A J AC 47 µF,10V,Electrolytic
C839 VCCSCY1HL2R0C J AD 2 pF,50V
C840,841 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C842 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C843 VCKYCY1EF104Z J AA 0.1 µF,25V
C844 VCKYCY1HB682K J AA 0.0068 µF,50V
C845 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C846,847 VCKYCY1EF104Z J AA 0.1 µF,25V
C848 VCCSCY1HL390J J AD 39 pF,50V
C849 VCKYCY1EB563K J AD 0.056 µF,25V
C850 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C851 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C852 VCQYKA1HM222J J AB 0.0022 µF,50V,Mylar
C853 VCKYPA1HB472K J AB 0.0047 µF,50V
C855 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C857 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C858 VCKYCY1EF103Z J AA 0.01 µF,25V
C859 RC-GZA477AF1A J AC 470 µF,10V,Electrolytic
C860 VCKYCY1EF104Z J AA 0.1 µF,25V
C861 VCKYPA1HB222K J AA 0.0022 µF,50V
C862 VCKYPA1HB102K J AA 0.001 µF,50V
C863 VCKYCY1HB471K J AA 470 pF,50V
C864~869 VCKYCY1HB221K J AA 220 pF,50V
C871 RC-EZD476AF1C J AC 47 µF,16V,Electrolytic
C872 VCKYCY1EB104K J AD 0.1 µF,25V
C887 VCKYCY1HB272K J AA 0.0027 µF,50V
C901,902 RC-GZV227AF1H J AC 220 µF,50V,Electrolytic
[XL-1100H Only]
C903,904 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
[XL-1100H Only]
C905,906 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
[XL-1100H Only]
RESISTORS
VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
R7A0 VRS-CY1JB102J J AA 1 kohm,1/16W
R7A1 VRS-CY1JB102J J AA 1 kohm,1/16W
R7A2 VRS-CY1JB104J J AA 100 kohm,1/16W
R7A3 VRD-ST2EE101J J AA 100 ohm,1/4W
R7A4 VRS-CY1JB121J J AA 120 ohms,1/16W
R7A5 VRS-CY1JB103J J AA 10 kohm,1/16W
R7A6 VRS-CY1JB102J J AA 1 kohm,1/16W
R7A7 VRS-CY1JB102J J AA 1 kohm,1/16W
R7A8 VRS-CY1JB820J J AA 82 ohms,1/16W
R7A9 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R7B0 VRS-CY1JB103J J AA 10 kohm,1/16W
R80A VRS-CY1JB823J J AA 82 kohms,1/16W
R80B VRS-CY1JB683J J AA 68 kohms,1/16W
R80C VRS-CY1JB823J J AA 82 kohms,1/16W
R80E VRS-CY1JB823J J AA 82 kohms,1/16W
R80F VRS-CY1JB823J J AA 82 kohms,1/16W
R80G VRD-ST2CD683J J AA 68 kohms,1/6W
R101 VRD-ST2CD102J J AA 1 kohm,1/6W
R102 VRD-ST2CD102J J AA 1 kohm,1/6W
R104 VRS-CY1JB563J J AA 56 kohms,1/16W
R105 VRD-RT2HD271J J AA 270 ohms,1/2W
– 2 –
