NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-1000H/1100H
OTHER CIRCUITRY PARTS
CFW451 QCNWN0308SJZZ J AB Lead Wire
CFW701A,B QCNWN0292SJZZ J AD Flat Wire,3Pin [XL-1100H]
CFW701A,B QCNWN0294SJZZ J Flat Wire,2Pin [XL-1000H]
CFW852 QCNWN0303SJZZ J AB Lead Wire
CNP307 QCNCM010LAWZZ J AC Plug,11Pin
CNP607 QCNCM004CAFZZ J AB Plug,3Pin
1 CNP651 QCNCM017BSJZZ J AD Plug,3Pin
CNP701 QCNCM999BAFZZ J AD Plug,2Pin
CNP702 QCNCM999QAFZZ J AC Plug,15Pin
CNP703 QCNCM999LAFZZ J Plug,11Pin [XL-1000H Only]
CNP703 QCNCM999MAFZZ J Plug,12Pin [XL-1100H Only]
CNP707 QCNCM998CAFZZ J AE Plug,3Pin
CNP801 QCNCM039DSJZZ J AD Plug,4Pin
CNP802 QCNCW007RSJZZ J AF Socket,16Pin
CNP803 QCNCM035FSJZZ J AD Plug,6Pin
CNP804 QCNCM038BSJZZ J AB Plug,2Pin
CNP805 QCNCM004CAFZZ J AB Plug,3Pin
CNP806 QCNCM004CAFZZ J AB Plug,3Pin
CNS307 QCNCW010LAWZZ J AD Socket,11Pin
CNW3 QCNWN0288SJZZ J AE Flat Cable,16Pin
CNW607/CNS607
QCNWN0291SJZZ J AE Connector Ass’y,3/3Pin
CNW701/CNS701
QCNWN0271SJZZ J AD Connector Ass’y,2/2Pin
CNW702/CNS702
QCNWN0269SJZZ J AG Connector Ass’y,15/15Pin
CNW703/CNS703
QCNWN0298SJZZ J AG Connector Ass’y,12/12Pin
[XL-1100H Only]
CNW703/CNS703
QCNWN0299SJZZ J Connector Ass’y,11/11Pin
[XL-1000H Only]
CNW707/CNS707
QCNWN0125SJZZ J AE Connector Ass’y,3/3Pin
CNW803/CNS803
QCNWN0276SJZZ J AE Connector Ass’y,6/6Pin
CNW804/CNS804
QCNWN0290SJZZ J AD Connector Ass’y,2Pin
CNW805/CNS805
QCNWN0296SJZZ J AE Connector Ass’y,3/3Pin
CNW806/CNS806
QCNWN0270SJZZ J AE Connector Ass’y,3/3Pin
1 F651 QFS-D252ABGNI J AE Fuse,T2.5A L 250V
1 F653 QFS-D132ABGNI J AE Fuse,T1.25A L 250V
FE301 RTUNS0012AWZZ J AV FM Front End
J601 QJAKM0001SJZZ J AG Jack,Headphones
J801 VHPPLT130T2-1 J AM Jack,CD Degital Output
LCD701 RV-LX0012SJZZ J AR LCD Display[XL-1100H]
LCD701 RV-LX0014SJZZ J AP LCD Display[XL-1000H]
LMP701 RLMPP0001SJZZ J AT Lamp [XL-1100H Only]
M801 RMOTV0004SJM1 J AM Motor with Gear [CD Lid]
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408SJM1 J AR Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
1 RLY601 RRLYD0004SJZZ J AG Relay
RX701 VHLN61V380A-1 J AN Remote Sensor
SO301 QTANC9003SJZZ J AF Terminal,Antenna
SO401 QSOCJ0003SJZZ J AG Socket,Video/AUX Input
SO601 QTANA0007SJZZ J AF Terminal,Speaker
1 SO655 QSOCA0212AWZZ J AD Socket AC Input
SW709 QSW-K0004SJZZ J AD Switch,Key Type [On/Stand-by]
SW710 QSW-K0004SJZZ J AD Switch,Key Type
[CD Lid Open/Close]
SW711 QSW-K0004SJZZ J AD Switch,Key Type [FF/Preset Up]
SW712 QSW-K0004SJZZ J AD Switch,Key Type
[CD Play/Pause/Tuning Up]
SW713 QSW-K0004SJZZ J AD Switch,Key Type [Volume Up]
SW718 QSW-K0004SJZZ J AD Switch,Key Type [Volume Down]
SW721 QSW-K0004SJZZ J AD Switch,Key Type [Bass/Treble]
SW722 QSW-K0004SJZZ J AD Switch,Key Type [Memory/Set]
SW725 QSW-K0004SJZZ J AD Switch,Key Type
[CD Stop/Tuning Down]
SW726 QSW-K0004SJZZ J AD Switch,Key Type
[REW/Preset Down]
SW727 QSW-K0004SJZZ J AD Switch,Key Type [Function]
SW802 QSW-B0001SJZZ J AG Switch,Lever Type [CD Lid]
CD MECHANISM PARTS
301 NGERH0586AFZZ J AC Gear,Middle
302 NGERH0587AFZZ J AC Gear,Drive
303 MLEVP0010AWZZ J Rail,Guide
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCOVP1333AFSA J AF Cover,Mechanism
306 PCUSG0001AWSA J AD Cushion (Green)
307 PCUSG0004AWSA J AD Cushion (Red-Brown)
1 308 DCTRH8005SJ01 J BA Pickup Unit Ass’y
308- 1 ———— — Pickup Unit
(Not Replacement Item)
308- 2 NGERR0043AFZZ J AC Gear,Rack
308- 3 NSPRC0961AFZZ J Spring,Rack
701 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
702 XBBSD20P03000 J AA Screw,ø2×3mm
703 XBSSD26P06000 J AA Screw,ø2.6×6mm
704 XHBSD20P05000 J AA Screw,ø2×5mm
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408SJM1 J AR Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
200 GCABA1058SJSA J AM Front Cabinet [XL-1000H]
200 GCABA1058SJSB J AN Front Cabinet [XL-1100H]
201 GCABB1063SJSA J AL Bottom Cabinet [XL-1000H]
201 GCABB1063SJSB J Bottom Cabinet [XL-1100H]
202 GCOVA1007SJSA J AH Rear Panel [XL-1000H]
202 GCOVA1007SJSB J AK Rear Panel [XL-1100H]
203 GCOVA1005SJSA J AE Cover,Remote Sensor
204 GFTAT1008SJSA J AN CD Lid [XL-1000H]
204 GFTAT1008SJSB J CD Lid [XL-1100H]
205 LANGQ0002SJFW J AB Lug
206 HDECQ0054SJSA J AN Clear Panel,CD Lid [XL-1000H]
206 HDECQ0056SJSA J Clear Panel,CD Lid [XL-1100H]
207 HDECQ0051SJSA J AE Clear Panel,Display
208 JKNBZ0053SJSA J AF Knob,Operation A
209 JKNBZ0054SJSA J AF Knob,Operation B
210 LANGF0033SJFW J AB Bracket,Main PWB
211 LANGF0034SJFW J AB Bracket,Tuner PWB
212 LANGF0035SJFW J AC Bracket,Gear Box
213 LANGK0025SJFW J AE Bracket,Tuner PWB
214 LANGK0026SJFW J AB Cover,Lamp [XL-1100H]
214 LHLDZ1040SJSA J AD Cover,Lamp (LED) [XL-1000H]
215 LCHSM0014SJFW J AH Chassis
216 LHLDW1001SJZZ J AD Nylon Band
217 LHLDZ0133SJSA J LCD Holder,A [XL-1100H]
217 LHLDZ1038SJSA J AD LCD Holder,A [XL-1000H]
218 LHLDZ1034SJSA J AD LED Holder
219 LHLDZ1035SJSA J AE Gear Box
220 LHLDZ1036SJSA J AE Lid,Gear Box
221 LPLTP0001SJSA J AE Cam Plate [XL-1000H]
221 LPLTP0001SJSB J Cam Plate [XL-1100H]
222 MLEVP0006SJSA J AE Rotate Lever,CD Lid,Left
[XL-1000H]
222 MLEVP0006SJSB J Rotate Lever,CD Lid,Left
[XL-1100H]
223 MLEVP0007SJSA J AE Rotate Lever,CD Lid,Right
[XL-1000H]
223 MLEVP0007SJSB J Rotate Lever,CD Lid,Right
[XL-1100H]
224 NGERW0004SJSA J AE Drive Gear,A
225 NGERW0005SJSA J AE Drive Gear,B
226 NGERW0006SJSA J AG Drive Gear,C
228 PCOVU9002SJZZ J AB Felt,CD Lid Cover
229 PCOVZ1005SJSA J AE Indicator Panel
230 PCUSG0003SJZZ J AC Cushion,Leg
231 PGUMS0002SJZZ J Cushion,CD Lid
232 PRDAR0040SJFW J AL Radiator,Main
233 PRDAR0038SJFW J AE Radiator,Transistor
234 PREFL0001SJSA J AD LCD Diffusion Plate
235 PSHEP0003SJZZ J AE Sheet,LCD
236 PSHEP0004SJZZ J AD LCD Reflect Paper
237 QFSHD0001AWZZ J AB Holder,Fuse
238 TLABS0004SJZZ J AC Label,Laser
239 TLABS0036SJZZ J AB Label,Class 3A
240 TSPC-0216SJZZ J Label,Specification [XL-1000H]
240 TSPC-0230SJZZ J Label,Specification [XL-1100H
For U.K.]
240 TSPC-0252SJZZ J Label,Specification [XL-1100H
For Europe]
601 LX-EZ0001SJFN J AB Screw,ø2.5×10mm
602 LX-WZ7094AFZZ J AA Washer,Special Tipe
603 XEBSD25P08000 J AA Screw,ø2.5×8mm
604 XEBSD25P10000 J AA Screw,ø2.5×10mm
605 XEBSD25P12000 J AA Screw,ø2.5×12mm
606 XEBSF25P08000 J AA Screw,ø2.5×8mm
607 XHBSD20P05000 J AA Screw,ø2×5mm
608 XHBSD30P06000 J AA Screw,ø3×6mm
609 XHBSD40P08000 J AA Screw,ø4×8mm
610 XJBSD30P06000 J AA Screw,ø3×6mm
611 XJBSD30P08000 J AA Screw,ø3×8mm
612 XJBSD30P10000 J AA Screw,ø3×10mm
613 XJBSD30P14000 J AA Screw,ø3×14mm
614 XJBSF30P08000 J AA Screw,ø3×8mm
615 XJBSF30P10000 J AA Screw,ø3×10mm
– 4 –
