Sharp XL-55

– 13 –
XL-55/55C
SW700 VOLUME ON—OFF
SW701 POWER ON/STAND-BY ON—OFF
SW702 FUNCTION ON—OFF
SW703 STOP/CLEAR,TUNING DOWN ON—OFF
SW704 PLAY/CD PAUSE,TUNING UP ON—OFF
SW705 BASS/TREBLE ON—OFF
SW706 MEMORY/SET ON—OFF
• The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
( ) indicates AM
< > indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
• Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
• Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
• Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means micro-micro-farad and the unit of the
capacitor without such a symbol is microfarad. As to
electrolytic capacitor, the expression “capacitance/withstand
voltage” is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
• Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
REF. NO
DESCRIPTION
POSITION POSITIONREF. NO
DESCRIPTION
SW707 REC/PAUSE ON—OFF
SW708 REW/PRESET DOWN ON—OFF
SW709 FF/PRESET UP ON—OFF
SW800 PICKUP IN ON—OFF
SW801 CD LID OPEN/CLOSE ON—OFF
SW901 FOOL PROOF ON—OFF
SW902 CAM ON—OFF
ECB
(S)(G)(D)
(1) (2) (3)
FRONT
VIEW
FRONT
VIEW
BCE
FRONT
VIEW
2HA1015 GR
2HC1815 GR
2SC2001 K
2SK2541
HSB562 C
KRA102 M
KRA107 M
KRC102 M
KRC104 M
KRC107 M
SC1674 C
KTC2026 Y
MPG3372X
SVC348S
KDV147B
1 2 3
TYPES OF TRANSISTOR AND LED
Figure 13 TYPES OF TRANSISTOR AND LED
