– 3 –
XL-55/55C
NAMES OF PARTS
1.CD Compartment
2.CD Eject Button
3.Volume Control
4.Cassette Compartment
5.Headphone Jack
6.Power On/Stand-by Button
7.Function Selector Button
8.CD or Tape Stop, Tuning Down Button
9.CD Play or Pause, Tape Play,
Tuning Up Button
10.Bass/Treble Selector Button
11.Memory/Set Button
12.Tape Record Pause Button
13.CD Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down Button
14. CD Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up Button
15.Timer Play Indicator
16. Tape Record Indicator
17. Sleep Indicator
18.CD Random Play Indicator
19.Memory Indicator
20. FM Stereo Mode Indicator
21. FM Stereo Receiving Indicator
22.Surround Indicator
23. CD Play Indicator
24.CD Repeat Play Indicator
25.CD Digital Output Jack
26.AC Power Input Jack
27.FM/AM Loop Antenna Jack
28.Video/Auxiliary (Audio Signal) Input Jacks
29.Subwoofer Output Jack
30. Speaker Terminals
15
1
2
3
4
5
17 18 19
20
24
23
21
16
22
26
6
10
789
11 12 13 14
28
30
29
27
25
1.Tweeter
2.Woofer
3.Speaker Wire
4.
Remote Control Transmitter
5.Clock Button
6.
Power On/Stand-by Button
7.
CD Button
8.
Tuner and Band Selector Button
9.Clear Button
10.
Memory Button
11.
CD Track Down, Tuner Preset Down Button
12.
CD Fast Reverse, Tuning Down,
Tape Rewind Button
13.
CD or Tape Play Button
14.Surround Button
15.
CD or Tape Stop Button
16.
Volume Up and Down Buttons
17.
Bass Up and Down Buttons
18.Timer Button
19.Sleep Button
20.
Video/Auxiliary Button
21.
Tape Button
22.Repeat Button
23.Random Button
24.
CD Track Up, Tuner Preset Up Button
25.
CD Fast Forward, Tuning Up,
Tape Fast Forward Button
26.
Tape Record Pause Button
27.
CD Pause Button
28.
Treble Up and Down Buttons
Buttons with " " mark in the illustration can be operated on the re-
mote control only.
3
2
1
4
5
16
17
6
18
28
19
20
21
23
24
25
26
27
22
7
8
9
10
11
12
13
15
14
Speaker grilles are removable:
Make sure nothing comes into contact with the
speaker diaphragms when you remove the
speaker grilles.
