SETTING THE CLOCK
In this example, the clock is set for the 12-hour
(AM 12:00) system.
3
Turn the jog dial to select the time display
mode.
"AM 12:00" → The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"0:00" → The 24-hour display will appear.
(0:00 - 23:59)
Note that this can only be set when the unit
is first installed or it has been reset.
4
Press the MEMORY/SET button.
5
Adjust the hour by turning the jog dial.
When the jog dial is turned one click clockwise,
the time will increase by 1 hour. When it is
turned one click counterclockwise, the time will
decrease by 1 hour.
Keep turning the jog dial to change the time
continuously.
When the 12-hour display is selected, "AM" will
change automatically to "PM".
6
Press the MEMORY/SET button.
7
Adjust the minutes by turning the jog dial.
When the jog dial is turned one click clockwise,
the time will increase by 1 minute. When it is
turned one click counterclockwise, the time will
decrease by 1 minute.
Keep turning the jog dial to change the time
continuously.
The hour setting will not advance even if min-
utes advance from "59" to "00".
8
Press the MEMORY/SET button.
The clock starts operating from "0" seconds.
(Seconds are not displayed.)
Note:
In the event of a power failure or when the AC
power cord is disconnected, the clock display
will go out.
When the AC power supply is restored, the
clock display will flash on and off to indicate
the time when the power failure occurred or
when the AC power cord was disconnected.
If this happens, follow the procedure below to
change the clock time.
To change the clock time:
Perform steps 1, 2 and 5 - 8 above.
To change the time display mode:
Perform steps 1 - 3 in the section "RESET-
TING THE MICROCOMPUTER".
Perform steps 1 - 8 above.
Jog dial
(Main unit operation)
CLOCK/TIMER/
SLEEP
MEMORY/
SET
AM 12:00 0:00
2
3
4
5
6
7
8
1
Press the CLOCK/TIMER/SLEEP button to
enter the time check mode.
2
Within 3 seconds, press the MEMORY/SET
button.
1
2
RIGHT
USING EXTERNAL UNITS
CD digital output (optical)
The CD digital signal from this unit can be re-
corded by other DAT or MiniDisc recorders.
1
Remove the DIGITAL OUT jack cover.
2
Use a commercially available digital cable to con-
nect the unit to the OPTICAL IN jack of a
MiniDisc recorder or a DAT.
3
Put the external unit in the recording mode.
4
Play a CD on this unit.
Commercially available digital cable
Before plugging in or unplugging the headphones,
make sure the volume level is reduced.
Be sure your headphones have a 1/8" (3.5 mm) di-
ameter plug and are between 16 ohms and 50 ohms
impedance. The recommended impedance is 32
ohms.
When headphones are connected, the speakers are
disconnected automatically. Adjust the VOLUME con-
trol for desired volume.
Headphones
Note:
Only CD signals can be output from this unit to
other DAT or MiniDisc recorders.
RIGHT
LEFT
VIDEO/AUX
To the output
jack
To the line
output jack
LEFT
A cable [a 1/8" (3.5 mm) ste-
reo mini-plug to pin-plugs]
RCA cord
RCA cord
LEFT
RIGHT
RIGHT
LEFT
To the line output jack
Connect each plug completely. If the units are not
connected correctly, it may not be possible to re-
cord or playback properly.
Before connecting external units, turn the power
to this unit and external units off.
VIDEO/AUX (Audio signal) input
To listen to or record signals from external
sources (personal computer, VCR, etc.) through
this unit:
1
Use a separately available RCA cord or a sep-
arately available cable [a 1/8" (3.5 mm) stereo
mini plug to pin plugs] to connect the desired
external unit to the VIDEO/AUX jacks.
(red → right channel, white → left channel)
Notes:
When your computer is not equipped with an
audio output terminal, a PC sound board is
needed.
When using video equipment (Laser Disc player,
VCR), be sure to connect the audio output to this
unit and the video output to a television.
2
Press the POWER button to turn the power on.
3
Press the FUNCTION button until "AUX" appears
in the display.
4
Operate the external unit.
5
To record the sound from the external unit, per-
form steps 2 - 4 of the "Recording from the built-
in radio".
Notes:
To prevent hum interference, do not place this unit
near television receivers and be careful not to turn the
computer volume up too high.
When turning the computer on or off, noise may be
heard, depending on the model.
Before turning your computer on or off, put the
POWER button on this unit in the stand-by mode, or
decrease the volume.
When an external unit with a built-in microphone or a
mixing microphone function is connected to this unit,
howling may occur due to feedback. Decrease the
volume of this unit or the microphone volume of the
external unit, or move the microphone away from the
speakers.
