References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may
be some deviations from these values in individual units.
General
(*) This power consumption value is obtained when the unit is in the
power stand-by mode.
Amplifier
Tuner
CD player
Cassette deck
Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on: 18 W
Power stand-by: 0.6 W(*)
Dimensions Width: 138 mm (5-7/16")
Height: 212 mm (8-11/32")
Depth: 218 mm (8-19/32")
Weight 2.6 kg (5.6 lbs.)
Output power PMPO: 26 W (total)
MPO: 13 W (6.5 W + 6.5 W) (DIN 45 324)
RMS: 10 W (5 W + 5 W) (DIN 45 324)
Output terminals Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
80 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35% (DIN 45 511)
Type 2 way speaker system
Maximum input
power
10 W
Rated input power 5 W
Impedance 4 ohms
Dimensions Width: 135 mm (5-5/16")
Height: 211 mm (8-5/16")
Depth: 180 mm (7-3/32")
Weight 1.5 kg (3.3 lbs.)/each
