XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS
1 DBDYTA194WEF0 BD N J Top Body Ass'y (10X-L)
1 DBDYTA195WEF0 BD N J Top Body Ass'y (MB50X-L)
1 DBDYTA196WEF0 BE N J Top Body Ass'y (11XC-L)
1 DBDYTA197WEF0 BE N J Top Body Ass'y (HB007X-L)
1 DBDYTA198WEF0 BE N J Top Body Ass'y (10S-L)
1-1 Not Available - N - Top Body
1-2 HDECPA027WJSA AD J Led Cover
1-3 HiNDPB309WJSA AH J Operation Cover (10S-L)
1-3 HiNDPB309WJSB AH J Operation Cover (10X-L/11XC-L)
1-3 HiNDPB309WJSC AH J Operation Cover (MB50X-L/HB007X-L)
1-4 JBTN-A463WJSA AF J Power Button
2 Not Available - N - Bottom Body Ass'y
2-1 CDORUA064WEF0 AQ N J Lamp Door Ass'y
2-1-1 Not Available - N - Lamp Door
2-1-2 LX-BZ3274CEFN AE J Screw
2-1-3 XRESJ30-06000 AA J E-Ring
2-1-4 PSLDHA042WJFW AF J Shield
2-2 DBDYUA234WEF0 BM N J Bottom Body Ass'y (10X-L)
2-2 DBDYUA235WEF0 BM N J Bottom Body Ass'y (MB50X-L)
2-2 DBDYUA236WEF0 BM N J Bottom Body Ass'y (11XC-L)
2-2 DBDYUA237WEF0 BM N J Bottom Body Ass'y (HB007X-L)
2-2 DBDYUA238WEF0 BM N J Bottom Body Ass'y (10S-L)
2-2-1 Not Available - N - Bottom Body
2-2-2 LX-NZ3120CEFW AB J Nut, x1
2-2-3 LX-NZ3144CEFW AC J Nut, x5
2-2-4 LHLDWA161WJZZ AD N J Wire Holder
2-3 GLEGPA030WJSA AK J Rear Adjuster
2-4 GLEGPA036WJSA AP J Front Adjuster
2-5 HDECPA028WJSA AE J R/C Cover
2-6 XEBSN30P08000 AA J Screw (Front Adjuster)
2-7 Not Available - - Filter Ass'y (Front)
2-7-1 LHLDZA781WJKA AF J Filter Holder (Front)
2-7-2 PFiLDA025WJZZ AK J Filter
2-8 Not Available - -
Filter Ass'y (Rear)
2-8-1 LHLDZA782WJKA AF J Filter Holder (Rear)
2-8-2 PFiLDA025WJZZ AK J Filter
2-9 LX-HZ3105CEFN AB J Screw
2-10 MLEVPA036WJK0 AF N J SW lLever
2-11 QCNW-E821WJQZ AN N J LF Wire
4 ----- - - Refer to Optical Mechanism Parts
5 AN-XR10L2 - J Lamp Unit
8 DSETUD147FMG1 BZ N J BALLAST POWER Ass'y (with Ballast Control Unit)
8-1 Not Available - N - BALLAST POWER Unit
8-2 DUNTKD148WEF4 BE N J BALLAST CONTROL Unit
9 DUNTKD164WEF4 AN N J R/C RECEIVER Unit
11 DUNTKE004FMF0 CN J MAIN Unit (10S-L)
11 DUNTKE004FMF1 CN N J MAIN Unit (10X-L/11XC-L/MB50X-L/HB007X-L)
11-1 PSLDMA722WJFW AL J Shield
11-2 PSLDMA726WJFW AF J MAIN PWB Shield
11-3 PSPAZA913WJKZ AB J Shield Spacer
12 HINDPC073WJZZ AC N J PSB Label (10X-LK)
12 HINDPC074WJZZ AG N J PSB Label (10S-LK)
13 LHLDZA579WJKZ AH J Speaker Holder
14 LHLDZA580WJKZ AD J Suport, x2
15 LHLDZA590WJKZ AD J PWB Suport
17 LX-BZ3100CEF7 AA J Screw, x11
20 NFANRA070WJ00 AY J Exhaust Fan (Lamp)
21 NFANRA069WJ00 AT J Exhaust Fan (Power) , x2
23 PCOVNA008WJZZ AE J Power Unit Duct B
24 PCOVNA009WJZZ AE J Power Unit Duct C
25 PCOVWA004WJKZ AH J Power Insulator (Front)
26 PCOVWA005WJKZ AH J Power Insulator (Rear)
29 PSLDMA720WJFW AM J Ballast Shield (Upper)
30 PSLDMA721WJFW AV J Ballast Shield (Lower)
31 PSPAGA276WJZZ AP J Fan Rubber, X3
33 PZETKA128WJKZ AN J Power Insulator Bottom
35 QCNW-D518WJQZ AM J EA Wire
36
QCNW-D575WJPZ AR J Baimetal Wire
39 RSP-ZA085WJQZ AP J Speaker
41 XBBSN30P08000 AA J Screw, x1
42 XBPS830P08JS0 AB J Screw, x2
43 XEBSN30P12000 AA J Screw, x19
44 TLABZA956WJZZ AB J WEEE Mark Label (10S-LE/K, 10X-LE/K)
45 Not Available - - Shaft
46 RH-HXA025WJPZ AP J Thermistor
47 LHLDW1226CEZZ AC J Wire Holder, x2
48 PSPAZA875WJKZ AC J Spacer, x2
49 XBBSN30P06000 AA J Screw, x2
