Sharp XR-10X-L User Manual

XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
1 – 1
XR-10X-L
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] Specifications
Projector
XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-10S-L/XR-HB007X-L
NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/PAL-60/SECAM/DTV480I/DTV480P/
DTV540P/DTV576I/DTV576P/DTV720P/DTV1035I /DTV1080I/DTV1080I-50
Single Chip Digital Micromirror Device
TM
(DMD
TM
) by Texas Instruments
Panel size: [XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-HB007X-L] 0.55" (14 mm), 1chip XGA DMD
[XR-10S-L] 0.55" (14 mm), 1chip SVGA DMD
No. of dots: [XG-MB50X-L/XR-11XC-L/XR-10X-L /XR-HB007X-L ] 786,432 dots (1,024 [H] x 768 [V])
[XR-10S-L] 480,000 dots (800 [H] x 600 [V])
[XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-10S-L/XR-HB007X-L] 1-1.15 zoom lens, F2.4-2.6, f = 19.0-21.9 mm
[XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-10S-L/XR-HB007X-L] 220 W DC lamp (AN-XR10L2)
15-pin mini D-sub connector
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
PR: 0.7 Vp-p, 75 Ω terminated
[XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-HB007X-L] 600 TV lines (DTV720P)
[XR-10S-L] 520 TV lines (DTV720P)
15-pin mini D-sub connector
RGB separate/sync on green type analog input: 0-0.7 Vp-p, positive, 75 Ω terminated
HORIZONTAL SYNC. SIGNAL: TTL level (positive/negative)
VERTICAL SYNC. SIGNAL: Same as above
4-pin mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
RCA connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω
terminated
45-85 Hz
15-70 kHz
12-108 MHz
9-pin mini DIN connector
φ3.5 mm minijack or RCA terminal: 0.5 Vrms, more than 22 kΩ (stereo)
φ3.5 mm minijack: 0.5 Vrms, less than 2.2 kΩ
4 cm x 2.85 cm oval x 1
AC 100-240 V
[XG-MB50X-L/XR-11XC-L/XR-10X-L/XR-10S-L/XR-HB007X-L] 3.0 A
50/60 Hz
XG-MB50X-L/XR-10X-L/XR-HB007X-L 298 W ("Bright" mode)/229 W ("Eco + Quiet" mode) with AC 100 V
XR-11XC-L/XR-10S-L 288 W ("Bright" mode)/223 W ("Eco + Quiet" mode) with AC 240 V
4.7 W (AC 100 V) - 6.1 W (AC 240 V)
XG-MB50X-L/XR-10X-L/XR-HB007X-L 1,120 BTU/hour ("Bright" mode)/860 BTU/hour ("Eco + Quiet" mode) with AC 100 V
XR-11XC-L/XR-10S-L 1,080 BTU/hour ("Bright" mode)/840 BTU/hour ("Eco + Quiet" mode) with AC 240 V
41Fto95F(+5Cto+35C)
-4Fto140F(-20Cto+60C)
Plastic
38 kHz
12
13
/ 32 "ıx 4
19
/ 64 "ıx 11
1
/ 32 "ı(315 (W) x 109 (H) x 280 (D) mm) (main body only)
12
13
/ 32 "ıx 4
47
/ 64 "ıx 11
37
/ 64 "ı(315 (W) x 120 (H) x 294 (D) mm) (including adjust-
ment foot and projecting parts)
8.6 lbs. (3.9 kg)
Remote control, Power cord, RGB cable, 3 RCA to 15-pin D-sub cable, DIN-D-
sub RS-232C adaptor, Operation manual, Dust filter
Product type
Model
Video system
Display method
DMD panel
Lens
Projection lamp
Component input signal
(INPUT1/2)
Horizontal resolution
Computer RGB input
(INPUT 1/2)/output
(OUTPUT) signal
S-video input signal
(INPUT 3)
Video input signal
(INPUT 4)
Vertical frequency
Horizontal frequency
Pixel clock
RS-232C terminal
Audio input signal
Audio output signal
(AUDIO OUTPUT 1-4)
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power consumption
(standby)
Heat dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Replacement parts
As a part of policy of continuous improvement, SHARP reserves the right to make design and
specification changes for product improvement without prior notice. The performance specifica-
tion figures indicated are nominal values of production units. There may be some deviations from
these values in individual units.
