XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
22
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] OPTICAL MECHANISM PARTS
3 CCAPHA024WJSA AG J Lens Cap Ass'y
4 CCHSKA019WEFB CG N J Optical Mechanism Unit
4-1 LCHSKA019WJF1 BG J Engine Base
4-2 LHLDZA572WJKZ AH J Mirror Holder
4-3 LHLDZA573WJKZ AK J Rod Holder Base
4-4 LHLDZA574WJKZ AH J Rod Holder Cover
4-5 CFiLWA097WEF0 BU J Colour Wheel Ass'y
4-5-1 PFiLWA097WJZZ BT J Colour Wheel
4-5-2 LHLDZA817WJFW AP J C/W Holder
4-5-3 PSHEGA043WJKZ AF J Sheet
4-5-4 XBBS920P05000 AB J Screw for C/W, x3
4-6 MSPRCA062WJFJ AB J Spring
4-7 MSPRPA061WJFW AE J Plastic Lens Spring
4-8 MSPRPA070WJFW AC J Rod Spring, x2
4-9 PCOVPA028WJSA AN J Focus Ring
4-10 PCOVPA029WJSA AM J Zoom Ring
4-11 PCOVZA056WJFW AF J Engine Cover
4-12 PCOVZA085WJKZ BA N J Lamp House
4-13 PDUC-A064WJKZ AR J Exhaust Duct
4-15 PLNS-A055WJZZ BV J Projection Lens
4-16 PLNS-A056WJZZ AX J Plastic Lens
4-17 PLNS-A057WJZZ AR J Illmi Lens 1
4-18 PLNS-A058WJZZ AS J Illmi Lens 2
4-19 PLNS-A059WJZZ BF J Rod
4-20 PMiR-A071WJZZ AS J Refrect Mirror
4-21 PSLDPA036WJFW AF J Projection Lens Aperture
4-22 PSLDPA061WJFW AG J DMD Aperture
4-23 PSLDPA038WJFW AD J Rod Aperture
4-24 PSLDPA039WJFW AF J Illmi Aperture 1
4-25 PSLDPA057WJFW AG J Illmi Aperture 2
4-26 PSLDPA042WJFW AE J House Shading board
4-27 PSPAZA769WJZZ AF J Dust Proof Spacer
4-29 XBBSN30P06000 AA J Screw M3*6, x13
4-30 XBBSN30P10000 AA J
Screw for C/W Holder, x2
4-31 XBPS830P08JS0 AB J Screw, Pj Lns=4, Mir=2
4-32 XEBSN30P08000 AA J Screw for Duct1
4-34 TLABZB026WJZZ AE J MECHA No.LABEL
4-35 TLABZB027WJZZ AB J OPT MODEL LABEL
6 DUNTKD140WEF0 BT N J DMD Unit
7 DUNTKD141WEF4 AP N J PHOTO SENSOR Unit
16 LHLDZA612WJFW AL J Backer Plate
18 LX-BZA110WJF7 AC J DMD Screw, x4
19 MSPRCA062WJFJ AB J Spring For DMD, x4
22 NFANSA019WJZZ BB J Blower Fan Unit
27 PRDARA223WJFW AV J DMD Heat Sink
28 PSHEGA040WJZZ AE J Thermal Pad
32 PSPAZA768WJZZ AD J Backer Plate Sheet
37 QSOCZA105WJZZ AZ J DMD Socket (10X-L/11XC-L/MB50X-L/HB007X-L)
37 QSOCZA106WJZZ AZ J DMD Socket (10S-L)
38 RDMDPA013WJZZQ CY J DMD SVGA (10S-L)
38 RDMDPA027WJZZ CW N J 0.55 DMD XGA (10X-L/11XC-L/MB50X-L/HB007X-L)
40 XBBSN30P06000 AA J Screw, x2
