Sharp XR-10X-L User Manual

XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE004FMF0 CN N J MAIN Unit (10S-L)
N DUNTKE004FMF1 CN N J MAIN Unit (10X-L/11XC-L/MB50X-L/HB007X-L)
N DUNTKD140WEF0 BT N J DMD Unit
N DUNTKD141WEF4 AP N J PHOTO SENSOR Unit
N DSETUD147FMG1 BZ N J BALLAST POWER Ass'y (with Ballast Control Unit)
N Not Available - -
BALLAST POWER Unit
Order the BALLAST POWER Ass'y (DSETUD147FMG1) when replacing power ballast
unit (DUNTKD147WEF6).
N DUNTKD148WEF4 BE N J BALLAST CONTROL Unit
N DUNTKD164WEF4 AN N J R/C RECEIVER Unit
[2] DUNTKE004FMF0/1 (MAIN Unit)
C1701 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1702 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1703 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1704 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C1705 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1710 VCEAPF0JW226MY AB J Capacitor 22 6.3V Electrolytic
C1711 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1712 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1717 VCCCCY1HH220JY AA J Capacitor 22p 50V Ceramic
C1718 VCCCCY1HH220JY AA J Capacitor 22p 50V Ceramic
C1721 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1722 RC-KZA066WJZZY AB J Capacitor 1 25V Ceramic
C1723 RC-KZA066WJZZY AB J Capacitor 1 25V Ceramic
C1724 RC-KZA066WJZZY AB J Capacitor 1 25V Ceramic
C1725 RC-KZA066WJZZY AB J Capacitor 1 25V Ceramic
C1726 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1727 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1728 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1729 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1741 RC-KZA101WJZZY AC J Capacitor 10 6.3V Ceramic
C1742 RC-KZA101WJZZY AC J Capacitor 10 6.3V Ceramic
C1743 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1745 VCKYCY1HB332KY AA J Capacitor 3300p 50V Ceramic
C1746 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C1748 VCAAPD1AJ686MY AE J Capacitor 68 10V Electrolytic
C1749 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1750 RC-KZA041WJZZY AC J Capacitor 10 10V Ceramic
C1751 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1752 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C1753 RC-KZA041WJZZY AC J Capacitor 10 10V Ceramic
C1754 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C1755 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1760 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1761 VCEAPF1CW336MY AD J
Capacitor 33 16V Electrolytic
C1762 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1763 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1764 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1765 RC-KZA101WJZZY AC J Capacitor 10 6.3V Ceramic
C1766 VCEAPF0JW226MY AB J Capacitor 22 6.3V Electrolytic
C1767 RC-KZA101WJZZY AC J Capacitor 10 6.3V Ceramic
C1768 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1769 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1770 VCEASH0JN476MY AC J Capacitor 47 6.3V Electrolytic
C1771 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1773 VCKYCY1HB152KY AA J Capacitor 1500p 50V Ceramic
C1774 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1775 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1778 VCAAPD1AJ686MY AE J Capacitor 68 10V Electrolytic
C1779 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1780 RC-KZA041WJZZY AC J Capacitor 10 10V Ceramic
C1781 RC-KZA041WJZZY AC J Capacitor 10 10V Ceramic
C1782 VCCCCY1HH220JY AA J Capacitor 22p 50V Ceramic
C1784 VCCCCY1HH220JY AA J Capacitor 22p 50V Ceramic
C1785 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1791 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1792 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1793 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1794 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1795 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C1796 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1797 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1798 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C2001 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2002 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C2003 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2004 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2006 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2007
VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2009 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2010 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2012 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2014 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C2015 VCEAPF0JW107MY AC J Capacitor 100 6.3V Electrolytic
