SADP & SADP-D Specification
Accuracy:
+/-1PPM , (+/-3 deg.C DP Red Spot, +/-4 deg.C DP, all others).
Type:
Portable hygrometer in stove enamelled zinc plated steel and alloy
case, complete with padded carrying case. For table top or portable
use with desiccant chamber for rapid readings. Certified intrinsically
safe for operation in hazardous areas.
ATEX: Intrinsically Safe to Ex II I G Ex ia IIC T6 Ga
FM: Intrinsically Safe Class 1, Division 1, Groups A&B, C, D, T6.
Dimensions / Weight:
Overall dimensions: 202mm x 225mm x 276mm High (320mm with
head extended) Weight: 4 Kg approx.
Display:
SADP 12cm Taut Band indicating meter showing Dewpoint and
ppm, with amplified range of 0-10ppm on TR versions.
SADP-D 2cm 3 1/2 Digit LCD with battery check symbol.
Sensor Connection:
Internal.
Power Supply:
9V DC ( 6 x VARTA 2014 R14 cells ) Internal
Sampling:
Pressure: atmospheric with flow rate of 5 - 10 litres/minute
Outputs:
None.
Calibration:
Autocal on all but Blue range.
Accessories / Options:
SU4 Lo, Med or Hi Sample system for sample conditioning
pressurised gases to atmospheric conditions and controlled flow.
Sensor Type {r}:
Purple: {P}
Red: {R}
Sensor Range:
-100 / 0 deg.C DP, 0-6000ppm, (auto-cal)
-80 / -20 deg.C DP, 0-1000ppm, and 0-10 on TR version, (auto-cal)
Grey : {G} -80 / 0 deg.C DP, 0 - 6000 ppm, and 0-10 on TR version, (auto-cal)
Blue : {Bl} -80 / +20 deg.C DP, 0 - 23,000 ppm (manual-cal)
To Order:
Analogue versions SADP {r}: suffix TR if required for G and R
ranges only.
Digital Versions SADP-D-{r}
