Shel lab SCO5A - CO2 Supply Connection and Stopper Installation

22 | Page
INSTALLATION
CONNECT TO THE CO
2
SUPPLY
Note: See page 9 for CO
2
supply requirements.
Connect the supply source to each incubator.
• The SCO10A requires a CO
2
supply for each chamber.
Do not initiate a flow of CO
2
to the incubator at this time.
End of Procedure
CO
2
to Chamber
“IN”
Connects to 3/16”
(4.76 mm) ID Tubing
“IN”
Optional Tubing Kit
with Inline HEPA Filter
Dual-Stage CO
2
Pressure Regulator
SCO5A
SCO10A
“IN”
