Shell NewMotion Business Pro 2.1 User Manual

INSTALLATIEHANDLEIDING – P6 VERSION 0129NM02INT01 MANUEL D’INSTALLATION – P6 | P6 091NM20INT04
EN NL FRDE
Way of mounting
Standard: charge
point wall bracket
mounting
Optional pole
mounting
Optional concrete
base (for in soil) for
pole
Optional Wall bracket
for two NewMotion
charge points
Required tools & additional materials
(not provided)
- Installation materials (power cable and
cable mount clips, RCD(‘s), MCB(‘s), etc.)
- Network switch (optional and not sold
by NewMotion)
- UTP cable(s) (CAT5 or CAT6)
- RJ45 UTP cable crimp tool
- RJ45 connectors
- 5 x screws (at least 6.3 x 60/70) and
plugs for mounting in wall
- Drill and bit
- Torx screwdrivers (T20 and PH3)
- Voltage tester
- Tape measure
- Spirit level
- All mentioned for standard mounting
- Pole (sold separately)
- 4 x M8 wedge bolts or chemical
anchors, plus nuts and washers
- All mentioned for pole mounting
- Concrete base (sold separately)
- DIN 912 HEX allen key (size 6)
- Shovel
- All mentioned for standard mounting
- 4 x screws (at least M8 x 70)
- Pole (sold separately)
Package contents charge point
- Charge point
- Wall bracket
- Rubber grommets (various sizes)
- 2 x plastic spacers
- Sticker sheet for the sides of the
charge point
- 1 x M4 x 20 mm bolt (Torx)
- 6 x M4 x 12 mm bolts (Torx)
- 2 x M8 x 12 mm bolts (PH) plus
washers
- Optional: Tethered charge cable
- 4 x M8 x 12 mm bolts (PH) plus
washers
- 4 x M8 x 35 mm bolts (HEX DIN 912)
plus washers
- 4 x M8 x 12 mm bolts (PH) plus
washers
