For detailed instructions please view the Shengmilo MX03 Video available in the COMMUNITY>>Video>>MX03
ASSEMBLY Video at www.shengmilo-bikes.com.
WARNING: an improperly secured front wheel and/or handlebar stem can cause loss of control, accidents, serious
injury, or death. Check that the front wheel and handlebar stem are properly secured to the bike during assembly and
before each ride.
Step 4: Perform a handlebar twist test to ensure the handlebar stem is secure.
A. Brace the front wheel. Stand at the front of the bike, facing the handlebar, and brace the front wheel between your feet
and lower legs.
B. Try to twist the handlebar. Hold both handlebar grips and push forward with one hand while pulling back with the other.
Push and pull at the same time with about 20 lb (9 kg) of force with each hand.
C. Ensure the handlebar and wheel stay properly aligned. The handlebar and handlebar stem should be tightly secured
perpendicular to the front wheel.
D. Repeat the twist test pulling/pushing with the opposite hands, again with 20 lb (9 kg)of force pulling with one hand
and 20 lb (9 kg) of force pushing with the other.
E. If needed, align the handlebar and stem and torque the stem clamp bolts evenly to the specification for the handlebar
stem clamp bolts in the Recommended Torque Values table below. After torquing the stem clamp bolts to the proper
specification, perform the twist test again. If the handlebar still moves, contact Shengmilo Product Support.
