Sherwin-Williams 824102 - Technical Specifications; Model Comparison Data

19824111
Technical Data
Model 824101
(2030)
Model 824102
(2835)
Model 824103
(3040)
Model 824104
(3340)
Engine (4 cycle, air cooled) 5.5 HP Hondat
OHV
9 HP Honda OHV 11 HP Honda OHV 13 HP Honda OHV
Gasoline tank capacity 3.8 qt (3.6 L) 6.2 qt (6.1 L) 6.9 qt (6.5 L) 6.9 qt (6.5 L)
Water pump maximum working pressure 2400 psi (165 bar,
16.5 MPa)
3200 psi (221 bar,
22.1 MPa)
3400 psi (234 bar,
23.4 MPa)
3700 psi (255 bar,
25.5 MPa)
Water pump maximum flow 3 gpm (11 lpm) 3.5 gpm (13 lpm) 4 gpm (15 lpm) 4 gpm (15 lpm)
Inlet hose connection 3/4-in. garden
hose (f)
3/4-in. garden
hose (f)
3/4-in. garden
hose (f)
3/4-in. garden
hose (f)
Weight (without gun and hose) 103 lb (47 kg) 142 lb (64 kg) 151 lb (69 kg) 151 lb (69 kg)
Dimensions
Length
Width
Height
36.5 in. (927mm)
22.0 in. (533mm)
31.5 in. (788mm)
36.5 in. (927mm)
22.0 in. (533mm)
31.5 in. (788mm)
36.5 in. (927mm)
22.0 in. (533mm)
32.5 in. (813mm)
36.5 in. (927mm)
22.0 in. (533mm)
32.5 in. (813mm)
Maximum inlet water temperature 160_F (70_C) 160_F (70_C) 160_F (70_C) 160_F (70_C)
Sound data (measured per ISO 3744)
Sound power level
Sound pressure level
93.1 dB(A)
103.5 dB(A)
94.3 dB(A)
104.7 dB(A)
95.8 dB(A)
106.3 dB(A)
97.4 dB(A)
111.6 dB(A)
Wetted parts
High-pressure hose
Bypass hose
Pressure washer (including fittings)
Acrylonitrile and Buna-N cover and tube
Synthetic yarn and EPDM
Anodized aluminum, aluminum or bronze alloys, brass copper, Nylon-PTFEr
composite, ceramic, buna-N, cotton phenolic, 303, 304, and 316 stainless steel,
Polymide–12 thermoplastic, PTFEr, carbon steel, zinc with or without yellow
chromate plate
PTFEr is a registered trademark of the DuPont Company.
Hondat is a trademark of the Honda Corporation.
