Sherwood AX-5103 - User Manual

Other manuals for Sherwood AX-5103

Introduction13 pages

Questions and Answers

A
Adam EricksonJul 31, 2025
Why is there no sound from my Sherwood AX-5103 Amplifier?
- J
  Jonathan MooreAug 1, 2025
  If there's no sound, it might be due to several reasons: the speaker cords could be disconnected, both SPEAKER SELECTOR A and B buttons might be off, the volume could be too low, the MUTE button on the remote might be on, the input source might be incorrectly selected, or the connections between components could be wrong. To resolve this: * Check the speaker connections. * Switch the desired speakers on. * Adjust the volume. * Press the MUTE button to cancel the muting effect. * Select the correct input source. * Ensure all connections are correctly made.
E
Evan MyersAug 10, 2025
What to do if my Sherwood Amplifier has no power?
- M
  Marc BondAug 10, 2025
  If your Sherwood Amplifier isn't powering on, it could be due to a disconnected AC input cord or a faulty AC wall outlet. Make sure the cord is securely connected. Also, test the outlet with a lamp or another appliance to confirm it's working.
B
bakermatthewAug 21, 2025
What to do if my Sherwood AX-5103 is not recording?
- M
  Mary JonesAug 21, 2025
  If your Sherwood Amplifier isn't recording, the issue might stem from incorrect connections or incorrect operation of the tape deck (or MD recorder). Ensure all connections are correctly made and that you are operating the tape deck (or MD recorder) properly.

Summary

Introduction and Safety Information

Welcome and Initial Setup Notes

Congratulates the user on their purchase and advises reading the manual for proper operation and installation.

FCC Compliance and Placement Guidelines

Details FCC information for digital devices and provides guidelines for safe and proper unit placement to avoid damage.

Regional Voltage and Safety

Voltage Selection and Country-Specific Safety

Explains voltage requirements and safety precautions for units shipped to different regions globally.

System Connections

Connecting Audio Components

Illustrates how to connect various audio sources like turntables, CD players, and tuners to the amplifier.

Connecting System Control Devices

Details how to connect Sherwood components using the DIGI LINK system for integrated control.

Speaker and Power Connections

Connecting Loudspeakers

Provides instructions and notes on connecting speaker pairs (A and B) with correct polarity and impedance.

AC Power Outlet Usage

Explains the AC input cord connection and the function of the switched AC outlet.

Front Panel Controls Overview

Power and Indicator Controls

Describes the Power Switch, Standby Indicator, and Speaker Selector buttons/indicators.

Input and Audio Adjustment Controls

Details Input Selector, Volume, Bass, Treble, and Balance controls.

Special Function Controls and Jacks

Explains the Tone Direct Switch, Loudness Switch, Headphone Jack, and Remote Sensor.

Remote Control Operation

DIGI LINK III System Remote Functions

Details how to remotely control the amplifier and other Sherwood components via DIGI LINK III.

Remote Control Button Guide

Explains the functions of various buttons on the remote control unit.

Remote Control Usage

Remote Control Operating Range

Specifies the effective range and angle for operating the remote control unit.

Loading Remote Control Batteries

Provides instructions for installing batteries correctly and notes on battery types.

Basic Operation Procedures

Entering Standby and Operating Modes

Guides on how to turn the amplifier on from standby mode and turn it off.

System Power Synchronization

Explains how the amplifier's power status affects connected Sherwood components via DIGI LINK.

TAPE MONITOR Functionality

Describes how to use the TAPE 2 MONITOR function for listening to connected tape decks or equalizers.

Playback and Listening Adjustments

Adjusting Volume, Tone, and Balance

Instructions on adjusting listening levels using volume, bass, treble, and balance controls.

Using Loudness and Direct Modes

Explains how to use the Loudness and Tone Direct features for sound enhancement.

Headphone Listening

Details how to connect headphones for private listening and necessary speaker switch settings.

Recording Procedures

Recording with TAPE 1;MD

Step-by-step guide on how to record audio from a selected source to TAPE 1/MD.

Recording via TAPE 2 MONITOR

Instructions for recording audio using the TAPE 2 MONITOR connection.

Troubleshooting Guide

Resolving Power and Sound Issues

Lists common problems like 'No power' and 'No sound' with their possible causes and remedies.

Troubleshooting Recording Problems

Addresses issues related to 'No recording' and their solutions.

Technical Specifications

Audio Performance Specifications

Details power output, distortion, sensitivity, frequency response, and signal-to-noise ratio.

General Unit Specifications

Provides information on power supply, consumption, AC outlets, dimensions, and weight.

Sherwood AX-5103 Specifications

Audio Specifications

power output	2 X 100 W
total harmonic distortion	0.03 %
intermodulation distortion	0.05 %

Input Specifications

phono input sensitivity	3.0 mV
cd/tuner/tape input sensitivity	200 mV
phono input overload	200 mV

Signal to Noise Ratio

phono signal to noise ratio	75 dB
cd/tuner/tape signal to noise ratio	90 dB
crosstalk	70 dB

Frequency and Tone Control

phono frequency response	±1 dB
cd/tuner/tape frequency response	+0 dB, -2 dB
bass/treble control	±10 dB

Power

power supply	230 V~50 Hz
power consumption	190 W
ac outlet	TOTAL 100 W(0.43A) max.

Weight and Dimensions

dimensions	440 X 145 X 360 mm
dimensions (inches)	17-3/8 X 5-3/4 X 14-1/8 inches
weight	8.75 kg (19.3 lbs)
