SECTION 2 – OPERATION
2-18
The standard three-point linkage has easily-
adjustable sway bars ③ to control the lateral
movement of the lift arms.
NOTE: Cycle the three point linkage through the
entire travel and check for any interference with
rear tires. If interference is present, adjust sway
bars as needed.
TOOL BOX
A tool box ① with a latching lid, is located
behind the seat and between the ROPS uprights.
DRINK HOLDER
A drink holder ② is attached to the left fender,
for the operator's drink storage convenience.
