SECTION 3 – LUBRICATION AND MAINTENANCE
3-23
MAIN FUSE
The main 40-amp fuse ① is located on the LH
side of the engine, between the starter and the
alternator. This fuse protects the tractor's entire
electrical system.
To replace the main fuse:
1. Unplug the connector, exposing the fuse.
2. Remove the old fuse from the fuse holder
and replace.
IMPORTANT: Always replace this fuse with a
similar 40
amp fuse; DO NOT increase the
amperage rating.
HEADLAMP
If a headlamp fails to operate, the bulb must be
replaced. To change the bulb:
1. Open the tractor hood.
2. Pull up the connector ① and rubber ② the
housing.
3. Take off the spring.
4. Remove the bulb.
5. Install a new bulb and install the spring,
rubber and connector.
IMPORTANT: Be careful not to touch the bulb
with bare fingers. Oil from the fingers can
shorten the life of the bulb. Use a protective cloth
or glove when installing the new bulb.
