SECTION 3 – LUBRICATION AND MAINTENANCE
3-24
TAILLIGHT/FLASHER WARNING LIGHT/SIDE
LIGHT
The tractor is equipped with two tail lights ①
mounted on the rear board, and four flasher
warning lights ② mounted on the rear board/
ROPS, and two side lights ③ mounted on the
ROPS.
1. Remove the two screws securing the lens to
the housing.
2. Remove the lens, then remove the bulb.
3. Install a new bulb and reinstall the lens
and/or rim assembly.
INSTRUMENT LIGHTS
To change a burned out instrument bulb:
1. Release the hood latch and raise the hood.
2. Disconnect the headlight electrical harness
①.
3. Remove the two bolts and two locknuts
securing the hood hinge bracket ② to the
firewall crossmember ③ and carefully set
the hood aside.
