SECTION 4 – SXM54, SXM60 MOWER DECK
4-15
11. Disconnect the front linkage ① from the
mower deck using the spring-loaded handle
②.
12. Disconnect the front linkage from the tractor
using the spring loaded handle ③.
13. Repeat for the opposite side.
14. Start the engine on the tractor and place the
3 PT hitch control lever ① in the "raise"
position.
15. Place the height control lever ② in the
"LOCK" position.
16. Stop the engine on the tractor.
CAUTION
When rolling the mower deck from under the
tractor, be very careful not to strike the
hydraulic filter with the mower deck.
17. Carefully roll the mower deck out from under
the tractor.
To Next Page
