BEFORE USING THE QUICKSHIFTER YOU MUST ENSURE THE CORRECT SENSOR MOTION FOR
YOUR SHIFT SETUP IS SELECTED, PLEASE REFER TO THE FOLLOWING TABLE - OPTION SS
- To enter setting mode: Press and hold LB and RB together then power up the control box
by turning the ignition key on, engine kill switch must be in RUN position and gear in neutral.
Hold down the buttons for 3 seconds until the countdown timer elapses.
- To cycle through the main parameters press LB
- To enter a particular parameter press RB
- To exit one level up in the menu press and hold LB for 3 seconds.
- To exit the setting mode power down the control.
The following is a menu table for adjusting the control box parameters
Adjust the engine
interrupt time for
shifting gears
UP(1-2-3-4-5-6)
45ms - 95ms
(5ms increments)
(60ms – default value)
Controls the shift sensor
motion for shifting gears
UP(1-2-3-4-5-6)
PH = PUSH
PL = PULL
(PH – default value)
Sets the Launch Control
and Pit Limiter RPM
limits
When LC displays engage on
1st gear accelerate the
engine to the desired RPM
and press RB once to set the
limit
LC flashes 5 times to
indicate settings are
accepted
When PL displays engage
on 1st gear accelerate the
engine to the desired
speed and press RB once
to set the limit
PL flashes 5 times to
indicate settings are
accepted
q - 0/1/2/3
This parameter controls
the quickshifter magnum
level by allowing
controlled cylinder
volumes to be ignited in
the exhaust
q1
4 cylinder
volumes are
ignited in
the exhaust
q2
8 cylinder
volumes are
ignited in the
exhaust
(default after
reset)
q3
12 cylinder
volumes are
ignited in the
exhaust
L
Controls the launch
control magnum feature
L0
Deactivated
(default value)
Controls the ultra-
smooth shift feature
U1
Activated
(default value)
Shift sensor sensitivity
control - adjustable in 5
RPM ranges and 3 levels
of sensitivity
1 = 3000 - 5000 RPM
2 = 5000 - 7000 RPM
3 = 7000 - 9000 RPM
4 = 9000 - 11000 RPM
5 = above 11000RPM
A = low
b = medium
C = high
default values
(1A, 2b, 3c, 4c, 5c)
