6.7 Remote-Control Connector
63
Power Supply Unit
INSTRUCTION MANUAL
6
Table 6-5 EI-xx03MZ vs. EI-Dxx03M Pin Configuration Comparison Chart
-After Changing Settings (SEMI E74 Standard Mode)
Singal type Signals
Pin numbers
Compatibility
EI-xx03MZ
EI-Dxx03M
SEMI E74
Standard Mode
INPUT
START 2 15
Same function
STOP 3 16
RESET 4 17
LOW SPEED 6 33
GND(COMMON) 1 14
OUTPUT
(Relay
Output)
ROTATION
17：Make contact 29：Make contact
19：Common 30：Common
18：Break contact 4 ：Break contact
NORMAL
11：Make contact 25：Make contact
13：Common 26：Common
12：Break contact 2 ：Break contact
ACCELERATION
8：Make contact 23：Make contact
10：Common 24：Common
9 ：Break contact 1 ：Break contact
BRAKE
14：Make contact 27：Make contact
16：Common 28：Common
15：Break contact 3 ：Break contact
ALARM
27：Make contact 20：Make contact
28：Common 22：Common
26：Break contact 21：Break contact
WARNING
30：Make contact 11：Make contact
31：Common 13：Common
29：Break contact 12：Break contact
REMOTE
20：Make contact 31： Make contact
22：Common 32：Common
21：Break contact 5：Break contact
