47
Connection and communication with devices
Connection with all SHIMANO STEPS components
Junction [A]
SM-PCE1
SM-PCE02
Connect to drive unit
With free port
SM-PCE1
SM-PCE02
Connect to
switch unit
SM-JC40/SM-JC41
Connect to drive unit
Without free port
46
48
