Shimano Steps SW-E6010 User Manual

9
1
Cycle computer
• SC-E6000
• SC-E6010
6
Battery mount (external type)
• SM-BME60
• SM-BME61
• BM-E6000
• BM-E6010
• BM-E8010
2
Assist switch
• SW-E6000
• SW-E6010
7
Battery (built-in type) • BT-E8020
*3
3
Front gear / Crank arm
• FC-E6000
• FC-E6010
• SM-CRE60
8
Battery mount (built-in type) • BM-E8020
4
Drive unit
• DU-E6001
• DU-E6050
• DU-E6010
• DU-E6002
• DU-E6012
9
Battery charger
* 1: SM-BCE60+SM-BCC1
* 2: EC-E6000
5
Battery (external type)
• BT-E6000
• BT-E6001
*3
• BT-E6010
• BT-E8010
*3
*3 If the firmware version of the drive unit is 3.2.6 or lower, the battery may not operate properly. Update the firmware
version via E-TUBE PROJECT.
Specifications
Operating temperature
range: During discharge
-10 – 50˚C Battery type Lithium ion battery
Operating temperature
range: During charging
0 – 40˚C Nominal capacity
Refer to the user's manual
for the battery "UM-
70F0A". For the latest
information on manuals, see
the website
(http://si.shimano.com).
Storage temperature -20 – 70˚C Rated voltage 36 V DC
Storage temperatur
e
(Battery)
-20 – 60˚C Drive unit type Midship
Charging voltage 100 – 240 V AC Motor type Brush-less DC
Charging time
Refer to the user's manual
for the battery "UM-70F0A".
For the latest information on
manuals, see the website
(http://si.shimano.com).
Rated drive unit power 250 W
* The range of the assist function speed is different depending on the specifications.
DU-E6001, DU-E6010: 25 km/h or less
DU-E6050: 20 mile/h or less
