Shimano PD-EF102 - Page 11

11
Maintenance
Adjusting axle bearings
2. Remove lock nut A and lock nut B, etc.
Lock nut A
Lock nut B
3. Pull out the axle unit.
Axle unit
4. Use a bearing puller to pull out the inner bush.
(1) Insert the bearing puller into the pedal body.
Install an attachment that matches the inner bush to the bearing puller.
AttachmentHandle
