Maintenance
Adjusting axle bearings
3. With the cone locked, tighten the lock nut.
10 - 15 N·m
Lock nut
Cone
NOTICE
• The cones and lock nuts on both pedals have right-hand threads.
• Adjust the cone so as to achieve a smooth rotation without excess play when the
axle unit is set into the pedal.
PD-EF102/PD-GR400
* The shape differs depending on the model.
