15
Maintenance
Installing/removing the reflectors
(2) Position the reflector on the pedal and secure it with the screw.
* The shape differs depending on the model.
PD-EF102
1 - 1.5 N·m
Screw for fixing the reflector
Reflector
Plate for mounting the reflector
PD-EF202/PD-EF205
0.8 N·m
Plate for mounting the
reflector
Screw for fixing the reflector
Reflector
To Next Page
