Shimano SW-EN600-L User Manual

Names of parts
Power button
E-TUBE port
Light button
X button
Y button
Turns the main power of the bicycle
ON/OFF.
Turns the light connected to the drive unit
ON/OFF.
Increases a level of assistance each time
pressed.
Decreases a level of assistance each
time pressed.
LED1
LED2
Names of parts
8

Shimano SW-EN600-L Specifications

General

Brand	Shimano
Model	SW-EN600-L
Category	Switch
Language	English
