LED display
LED1
Displays the level of the battery mounted on the bicycle.
* This battery level display uses zero to indicate a battery level where assistance can no longer be performed.
SHIMANO STEPS provides an amount of battery separate from the assist function for additional equipment such
as lights and ABS. Therefore, the battery level may differ from that which can be checked with the battery LED.
Display Battery level
Green 100 - 21%
Red 20 - 11%
Flashing red 10% or less
LED2
Mainly used to display the current assist mode. The assist mode returns to OFF when the power is turned OFF.
* Refer to the “SHIMANO STEPS User's Manual” for details on the assist mode and walk assist mode operations.
Display State
OFF The assist mode is OFF.
Light blue
The assist mode with the lowest level of assistance.
(Push the Y button to turn LED2 OFF and disable the assist mode.)
Green The assist mode with an intermediate level of assistance.
Yellow
The assist mode with the highest level of assistance.
(Pressing the X button does not make the level of assistance any higher than this.)
Flashing yellow
Indicates the adjustment mode.
In this state, gear shifting operations cannot be performed with the switch unit (right).
Blue The assist mode is set to the walk assist mode.
Flashing blue Assistance is functioning in the walk assist mode.
Flashing red Refer to “Error indication.”
