-31-
Status 7 :
The thread wiper can't take the needle
thread up -
Solution :
(a)
Please double confirm the bottom trimmer have
always cut the needlethread. If the needle thread
didn't be cut out, the wiper is impossible to take
the needle thread up.(*)
(b) Please check the position of thread wiper have
followed the installation manual to set up in
correctly.
(c) Please check the return elasticity of top wiper
is too weak, or the wiper didn't move smoothly.
Remark :
If the needle thread didn't be cut by trimmer which will
cause the "Top Wiper" can't take the needle thread up. Please
use the thread clipper to cut the needle thread which didn't
be cut by under trimmer. To let the "Top Wiper" return
backto the initial place which to avoid the hook of wiper
crash theneedle.
Status 8 :
To step on the pedal in the front which
the machine didn't operate -
Solution :
(a)
Please check the green light on the Under Trimmer
Position Security Switch is be switched on or off.
(The green light locate at back side of machine
head) If the green light is be switch off which
meaning is that under thread trimmer didn't return
back the position, the Security Switch have broken
the electric power in automatic which to avoid
the Looper crash the under thread trimmer.
(b)
Please check the error code which be showed on
the screen of control box. then, to follow
instruction manual for solving the problem.
狀況7 ：撥線器無法將針線頭撥起時—
排除：
A 先試縫確認每次切線時，針線是否每次都
有被下切刀完全切斷；因針線未被下切刀
切斷時，撥線器則無法順利將線頭撥離針
板面。
B 檢查撥線器，安裝之位置是否有依前述說
明正確安裝。
C 檢查撥線器，回歸時彈力是否異常太弱，
有活動不良的情形。
註：
如是針線未被切斷導致撥線器無法將線頭拉出而卡
在針下方時，必須先用剪刀剪斷針線，使撥線器之
撥線勾針能回歸原點，否則會造成針與撥線勾針相
互碰撞的情形。
狀況8 ：前踩踏板、機器不能運轉時—
排除：
A 檢查保護下切刀組回歸定位之安全開關小
綠燈是否亮著(位於機頭後方，安全開關
上)。如未亮則表示下切刀組未回歸定位，安
全開關自動斷電以保護下切刀不被碰撞。
B 檢查電腦控制箱顯示之代號，再對照馬達
說明書之故障代號說明，排除問題。
-32-
(c) Please check the plug of junction line which
between the servo motor and control box. Have
the plug been plugged in well? Or, the plug has
plugged too loose which to cause the bad
connection.
Status 9 : To step on the pedal in rear which
the Thread Trimmer System and
Pressure Foot Lifter didn't operate -
Solution :
(a)
Please check the terminal of Top, Bottom Thread
Trimmer and Pressure Foot Lifter junction line
for which locate at backside of machine head.
If the terminal didn't connect well, the signal is
going to bad transmission to cause these moving
parts didn't operate.
(b) Please use your hand to push the Under Thread
Trimmer System and Thread Pull-Off Mechanism.
Then, Please check these mechanisms move
smoothly or not?
(c) Please check the error code which be showed
on the screen of control box. then, to follow
instruction manual for solving the problem.
Dear Users,
We hope this "Instruction & Maintenance Book"
could offer you more information about our
"Shing Ray" products and help you to solve these
unusual conditions of our machine.
If you have any further requested and some
problems about the maintenance, we are warmly
welcome you to contact with our distributor and
sloe agency in your country. All of them are
willing to service you. Finally, we are sincerely to
thanks all of yours continuing supports.
C 檢查機頭馬達與電腦控制箱之中繼線、插
頭是否有鬆脫或未插緊，而造成接觸不良
的情形。
狀況9 ：後踩踏板時，切刀組及自動
抬押腳全無動作之情形—
排除：
A 檢查機頭後方之連接端子上電線是否脫落，
造成各活動部位(下切刀、上切刀、抬押腳)
未接收到訊號，而無法動作。
B 用手動方式檢查切刀機構及鬆線機構是否
順暢無卡死情形。
C 檢查電腦控制箱上顯示之代號，對照說明
書上顯示之代號，對照說明書上之異常狀
況為何。
這本「操作說明書」希望能使您更了解星銳
公司的產品，也能助您排除一些異常狀況；
如有任何無法解決或維修上的問題，非常歡
迎您與我們各地區之經銷、代理商連絡，他
們都非常樂意為您服務，謝謝大家的愛護與
支持。
C 致 敬愛的用戶們：
C. CONCLUSION :
