97(111)
24.7.11 Bill of Electrical Parts (SHD-600) (400V)
24.7.12 Bill of Electrical Parts (SHD-800) (400V)
No. Symbol Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 50A 3P 400V 50/60Hz YE40305003000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 K5 Contactor* 220V 50/60Hz YE00602622000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 F1 Overload relay 1.4~2A YE01160140000
8 FU1 Fuse base** 2P YE41032200000
9 - Fuse** 1A YE46001000100
10 FU2 Fuse** 6*30mm 2A 250V YE41001000000
11 T Transformer* 300mA YE70402300700
12 S1 S2 Alternative switch 4P (WH) YE10210400000
13 S3 Alternative switch 6P (WH) YE10220600000
14 S4 Overheat protector* 15A BE85013000050
15 S5 Thermocouple* - BE90510000050
16 X1 Terminal board 2.5mm
2
YE61250040000
17 M1 Blower* 400V 50Hz 0.55kW BM30055000150
18 EH1 Pipe heater** 400V 50Hz 21kW BH70603800050
No. Symbol Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 50A 3P 400V 50/60Hz YE40305003000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 K5 Contactor* 220V 50/60Hz YE00602622000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 F1 Overload relay 2.2~3.2A YE01160220000
8 FU1 Fuse base** 2P YE41032200000
9 - Fuse** 1A YE46001000100
10 FU2 Fuse** 6*30mm 2A 250V YE41001000000
11 T Transformer* 300mA YE70402300700
12 S1 S2 Alternative switch 4P (WH) YE10210400000
13 S3 Alternative switch 6P (WH) YE10220600000
14 S4 Overheat protector* 15A BE85013000050
15 S5 Thermocouple* - BE90250000050
16 X1 Terminal board 2.5mm
2
YE61250040000
17 M1 Blower* 400V 50Hz 1.1kW BM30113230050
18 EH1 Pipe heater** 400V 50Hz 24kW BH70244000750
