24.7.13 Bill of Electrical Parts (SHD-1000) (400V)
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the item number
of the spare part is in accordance with the real object.
No. Symbol
Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 80A 3P 400V 50/60Hz YE40308003000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 K5 Contactor* 220V 50/60Hz YE00602722000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 F1 Overload relay 2.2-3.2A YE01160220000
8 FU1 Fuse base** 2P YE41032200000
9 - Fuse** 1A YE46001000100
10 FU2 Fuse** 6*30mm 2A 250V YE41001000000
11 T Transformer* 300mA YE70402300700
12 S1 S2 Alternative switch 4P (WH) YE10210400000
13 S3 Alternative switch 6P (WH) YE10220600000
14 S4 Overheat protector* 15A BE85013000050
15 S5 Thermocouple* - BE90250000050
16 X1 Terminal board 2.5mm
2
YE61250040000
17 M1 Blower* 400V 50Hz 1.1kW BM30113230050
18 EH1 Pipe heater** 400V 50Hz 32kW BH70324000750
To Next Page
